Cheap High Temperature Heat Resistant High Borosilicate Glass Tube
- Category: >>>
- Supplier: Nantong Geili Packaging Material Co. Ltd.
Share on (1601276970499):
Product Overview
Description
Product Description
Neutral borosilicate glass tube
Glass Tube Process
Glass Tube Parameters
Tubing for Syringer
Out Diameter(mm) | OD Tolerance(mm) | ISO Standard | Inner Diameter(mm) | ID Tolerance(mm) | ISO Standard |
6.85 | ±0.10 | ±0.10 | 4.65 | ±0.10 | ±0.10 |
8.15 | ±0.10 | ±0.10 | 6.35 | ±0.10 | ±0.10 |
10.85 | ±0.10 | ±0.10 | 8.65 | ±0.20 | ±0.20 |
14.45 | ±0.10 | ±0.10 | 11.85 | ±0.20 | ±0.20 |
17.05 | ±0.20 | ±0.20 | 14.25 | ±0.20 | ±0.20 |
22.05 | ±0.20 | ±0.20 | 19.05 | ±0.20 | ±0.20 |
Cartridge Tubing
Out Diameter(mm) | OD Tolerance(mm) | ISO Standard | Inner Diameter(mm) | ID Tolerance(mm) | ISO Standard |
8.65 | ±0.10 | ±0.10 | 6.85 | ±0.10 | ±0.10 |
10.85 | ±0.10 | ±0.10 | 8.65 | ±0.10 | ±0.10 |
10.95 | ±0.15 | ±0.15 | 9.25 | ±0.10 | ±0.10 |
11.6 | ±0.15 | ±0.15 | 9.65 | ±0.10 | ±0.10 |
14.00 | ±0.15 | ±0.15 | 12.00 | ±0.15 | ±0.15 |
14.45 | ±0.15 | ±0.15 | 11.85 | ±0.15 | ±0.15 |
18.25 | ±0.15 | ±0.15 | 16.05 | ±0.15 | ±0.15 |
Ampoules Tubing
Out Diameter(mm) | OD Tolerance(mm) | ISO Standard | Wall Thickness(mm) | ID Tolerance(mm) | ISO Standard |
10.75 | ±0.13 | ±0.15 | 0.50 | ±0.02 | ±0.03 |
12.75 | ±0.13 | ±0.15 | 0.50 | ±0.02 | ±0.03 |
14.75 | ±0.13 | ±0.15 | 0.55 | ±0.02 | ±0.03 |
17.75 | ±0.15 | ±0.20 | 0.60 | ±0.03 | ±0.04 |
22.5 | ±0.20 | ±0.25 | 0.70 | ±0.04 | ±0.04 |
Vials Tubing
Out Diameter(mm) | OD Tolerance(mm) | ISO Standard | Wall Thickness(mm) | ID Tolerance(mm) | ISO Standard |
16 | ±0.15 | ±0.15 | 1.0 | ±0.04 | ±0.04 |
22 | ±0.20 | ±0.20 | 1.0 | ±0.04 | ±0.04 |
24 | ±0.20 | ±0.20 | 1.0 | ±0.04 | ±0.04 |
30 | ±0.25 | ±0.25 | 1.2 | ±0.05 | ±0.05 |
Product Details
Company Profile
Certifications
FAQ
1.Your company is manufacturer or trading company?
We’re a worldwide China-based manufacturer which have over 16 years of manufacturing and trading experience in researching, developing and producing pharmaceutical products.
2.Will you provide samples?
Yes, samples are free, but the express cost will be paid by yourself. Usually we'll send them within2-3 days.
3.What’s your delivery time?
Regarding the standard bottles, if we have enough stock, can be sent within 7 days. Regarding OEM bottles, to bediscussed.
4.What service can you provide?
Free sample, OEM product, color and surface treatment, InspectionSupport.
