Nozzle diameter | Pressure MPA | Flow rate m ³/h | Range distance M | Nozzle diameter | Pressure MPA | Flow rate m ³/h | Range distance M |
0.2 | 20.5 | 27 | 0.4 | 63.7 | 49.5 | ||
0.3 | 25.1 | 34 | 0.5 | 71.3 | 52 | ||
0.4 | 29 | 39 | 0.6 | 78 | 56 | ||
0.5 | 32.5 | 43 | 0.7 | 84 | 59.5 | ||
0.2 | 24.6 | 29 | 0.4 | 72.4 | 50 | ||
0.3 | 30 | 35 | 0.5 | 81 | 54 | ||
0.4 | 34.8 | 41 | 0.6 | 88.7 | 58 | ||
0.5 | 38.9 | 45 | 0.7 | 95.6 | 62.5 | ||
0.2 | 29 | 31 | 0.4 | 81.7 | 52 | ||
0.3 | 35.4 | 37 | 0.5 | 91.3 | 56 | ||
0.4 | 41 | 42 | 0.6 | 100 | 59.5 | ||
0.5 | 45.9 | 47 | 0.7 | 107.9 | 63 | ||
0.3 | 41.4 | 38 | 0.5 | 102.5 | 57.5 | ||
0.4 | 48 | 44 | 0.6 | 112.3 | 61 | ||
0.5 | 53.7 | 49 | 0.7 | 121 | 64.5 | ||
0.6 | 58.8 | 52 | 0.8 | 129.7 | 68 | ||
0.3 | 48 | 42 | 0.5 | 121 | 62 | ||
0.4 | 55.5 | 47 | 0.6 | 133 | 64.8 | ||
0.5 | 62.2 | 51 | 0.7 | 145 | 68.2 | ||
0.6 | 68.1 | 54 | 0.8 | 152 | 70 |
Product name | KY-45Turboworm Spray Gun |
Main materials | Aluminum alloy, copper, stainless steel, nylon |
Scope of application | Agriculture, forestry, urban landscaping, industrial and mining dust removal |
Interface size | 1-1/2 "internal thread |
Work pressure | 0.2-0.5mpa |
Range | 22-41m |
Spray angle | 360 ° |
Adjustable spray angle | 24 ° |
