1 Polyimide Pi Film Coated Silicone Glue XINGHUIYU Self Adhesive Tape with Release Liner High temperature resistant 280
- Category: >>>
- Supplier: Huizhou Xinhuiyu Electronic Technology Co. Ltd.Huizhou Ltd.
Share on (1601277843481):
Product Overview
Description
Product Briefing
Polyimide tape is based on polyimide film and adopts imported silicone pressure sensitive adhesive. It has the properties of high and low temperature resistance, acid and alkali resistance, solvent resistance, electrical insulation (Class H) and radiation protection. Suitable for wave soldering of electronic circuit board to shield, protect gold finger and high-grade electrical insulation, motor insulation, and lithium battery positive and negative ear fixed.
Product Features
1. High and low temperature resistance
2. Acid and alkali resistance
3. Solvent Resistance
4. Electrical insulation (Class H)
5. Radiation Protection and other performance.
2. Acid and alkali resistance
3. Solvent Resistance
4. Electrical insulation (Class H)
5. Radiation Protection and other performance.
Product Applications
1. Wave soldering solder mask
2 protect the gold finger and high-end electrical insulation
3 motor insulation
4 lithium battery positive and negative ear fixed.
2 protect the gold finger and high-end electrical insulation
3 motor insulation
4 lithium battery positive and negative ear fixed.
Product Parameters
Product Number: | Film Thickness: | Total Thickness: | Adhesion to Steel: |
XHY-2535 | 25 microns | 35 microns | 4/25mm |
XHY-2545 | 25 microns | 45 microns | 5 N/25mm |
XHY-2550 | 25 microns | 50 microns | 5N/25mm |
XHY-2555 | 25 microns | 55 microns | 5.5 N/25mm |
XHY-2560 | 25 microns | 60 microns | 6 N/25mm |
XHY-2570 | 25 microns | 70 microns | 7 N/25mm |
XHY-5080 | 50 microns | 80 microns | 5.5 N/25mm |
XHY-50100 | 50 microns | 100 microns | 8 N/25mm |
XHY-75100 | 75 microns | 100 microns | 4.5 N/25mm |
XHY-75120 | 75 microns | 120 microns | 8 N/25mm |
XHY-100150 | 100 microns | 150 microns | 8 N/25mm |
XHY-125180 | 12.5 microns | 180 microns | 8 N/25mm |
Color | Amber |
Substrate | Polyimide film |
Adhesive | silica |
Storage conditions | 6 months from the date of purchase. Store the adhesive tape at 27℃-35℃ with 60% humidity in a room with constant temperature, avoiding direct sunlight. |
Long-term temperature resistance | 250℃ |
Short time temperature resistance | 280℃ |
General specifications | 25mm*33m/25mm*66m |
Master roll specifications | 500mm*2000m |
Width | 500mm |
Length | Customizable |
Company Profile
Enterprise Advantage
1. We are a source factory specializing in researching, developing, producing and selling high temperature resistant adhesive tapes.
2. We have more than 20 years of production experience and continuous product innovation.
3. We can customize the thickness, adhesion, length and width of the tape according to customers' needs.
4. Our products can be OEM, and the packaging can be made according to customers' requirements.
5. We deliver the products on time and at an affordable price, and we have a series of testing instruments to ensure the quality of our products.
6. We provide customers with pre-sale, sale and after-sale perfect service.
2. We have more than 20 years of production experience and continuous product innovation.
3. We can customize the thickness, adhesion, length and width of the tape according to customers' needs.
4. Our products can be OEM, and the packaging can be made according to customers' requirements.
5. We deliver the products on time and at an affordable price, and we have a series of testing instruments to ensure the quality of our products.
6. We provide customers with pre-sale, sale and after-sale perfect service.
Huizhou Xinhuiyu Electronic Technology Co., Ltd.
The company has established a business pattern based on various types of special adhesive tapes, high temperature tapes and other products, the main production of products are: Polyimide tape, including: single-sided, double-sided, anti-static, matte black, glossy black; PET silicone tape in various colors, composite fluoroplastic release film PI/PET tape, Lithium battery (acrylic) tape, Teflon tape, Acetic cloth Tape, Mylar tape, PI film, PET film, Fiberglass cloth tape, Composite PET red and white masking tape and other various electronic industrial products.
The company has been focusing on the cultivation of talent, has a number of high-quality and professional management personnel and technicians, from the receipt of orders, development, production, service has always been completed, from the audit of raw material suppliers, incoming inspection, production process inspection, final inspection, have a perfect quality management system to fully protect product quality.
is a large-scale high temperature tape manufacturer integrating R&D, production and sales. After years of development and accumulation, has a strong production capacity and specialized project development capabilities.
The company has established a business pattern based on various types of special adhesive tapes, high temperature tapes and other products, the main production of products are: Polyimide tape, including: single-sided, double-sided, anti-static, matte black, glossy black; PET silicone tape in various colors, composite fluoroplastic release film PI/PET tape, Lithium battery (acrylic) tape, Teflon tape, Acetic cloth Tape, Mylar tape, PI film, PET film, Fiberglass cloth tape, Composite PET red and white masking tape and other various electronic industrial products.
The company has been focusing on the cultivation of talent, has a number of high-quality and professional management personnel and technicians, from the receipt of orders, development, production, service has always been completed, from the audit of raw material suppliers, incoming inspection, production process inspection, final inspection, have a perfect quality management system to fully protect product quality.
Manufacturing Technique
Product quality control equipment
Holding Power Tester
Peeling force tester
Electrothermal constant temperature blast drying oven (temperature resistance test)
Tensile testing machine
Exhibition
Certifications
Our Advantages
1. Excellent mechanical properties
High bonding strength and tensile strength, good elasticity and elongation performance, and strong adaptability to interface deformation and cracking.
2. Stable chemical properties
With excellent chemical resistance,weather resistance and corrosionresistance, heat-resistant
3. Reliable application performance
lt has good adhesion, waterproofing, sealing, low temperature resistance, and tracking properties, as well as good dimensional stability.
Product packaging
How about Packaging & Shipping ?
1. Shipment in strict accordance with the unified packaging standards.
2. The delivery time is negotiable according to the order details.
3. 30% deposit, 70% payment before shipment
4. Customers can choose to ship by TNT, UPS, DHL, FEDEX (IE), Aramex or by air or sea.
5. Port of loading: Shenzhen
2. The delivery time is negotiable according to the order details.
3. 30% deposit, 70% payment before shipment
4. Customers can choose to ship by TNT, UPS, DHL, FEDEX (IE), Aramex or by air or sea.
5. Port of loading: Shenzhen
FAQ
Q: Why choose us?
A: We are a professional manufacturer with 20 years of production experience. Our factory is currently equipped with many large multi-functional machines, we do coating, rewinding and cutting, and we also have the most advanced fully automatic packaging machines with very strong production capacity.
Q: How long is your delivery time?
A: Normally within 15-20 days after deposit received.
Q: Do you provide samples? Is it free or extra?
A: Yes, our samples are free, customers pay the shipping cost.
Q: What are your payment terms?
A: Usually we can handle wire transfer, Visa, Western Union.
Q: Can our private logo/label be printed on the packaging?
A: Yes, your own private logo/label can be printed on the packaging according to your legal authorization, we have supported OEM & ODM services according to customers' requirements for many years.
Q: What about the payment?
A: For regular products，30% deposit in advance, 70% T/T, Cash
Q: How to control your quality?
A: We have omplete quality guarantee system: IQC FAS &Self checking for
each producing progress →OQC. And as below:
1). Before production: sending pre-production samples for checking.
2). During production: sending mass production samples for checking again.
3). Before shipment: customers' or the third parties' visit to our factory to
check the quality directly or any inspection is welcome!
4). After shipment: if there is any problem of our goods due to our mistake,
we will surely be responsible for it.
Q: How can we get detailed price list?
A:Please offer us detailed information of the product such as Size(length,
width,thickness),color,specific packaging requirements and purchasing quantity.
A: We are a professional manufacturer with 20 years of production experience. Our factory is currently equipped with many large multi-functional machines, we do coating, rewinding and cutting, and we also have the most advanced fully automatic packaging machines with very strong production capacity.
Q: How long is your delivery time?
A: Normally within 15-20 days after deposit received.
Q: Do you provide samples? Is it free or extra?
A: Yes, our samples are free, customers pay the shipping cost.
Q: What are your payment terms?
A: Usually we can handle wire transfer, Visa, Western Union.
Q: Can our private logo/label be printed on the packaging?
A: Yes, your own private logo/label can be printed on the packaging according to your legal authorization, we have supported OEM & ODM services according to customers' requirements for many years.
Q: What about the payment?
A: For regular products，30% deposit in advance, 70% T/T, Cash
Q: How to control your quality?
A: We have omplete quality guarantee system: IQC FAS &Self checking for
each producing progress →OQC. And as below:
1). Before production: sending pre-production samples for checking.
2). During production: sending mass production samples for checking again.
3). Before shipment: customers' or the third parties' visit to our factory to
check the quality directly or any inspection is welcome!
4). After shipment: if there is any problem of our goods due to our mistake,
we will surely be responsible for it.
Q: How can we get detailed price list?
A:Please offer us detailed information of the product such as Size(length,
width,thickness),color,specific packaging requirements and purchasing quantity.
