Low cost S6730 H24X6C 02353GFC 24*10GE SFP ports, 6*40GE/100GE QSFP28 ports S6700 Series HW network switch 24 port

Part Number

02352FSG

Model

S6730-H24X6C

Description

S6730-H24X6C (24*10GE SFP+ ports, 6*40GE QSFP28 ports, optional license for upgrade to 6*100GE QSFP28, without power module)

Chassis material

Metal

Height [mm]

43.6 mm

Depth [mm]

420.0 mm

Wide [mm]

442.0 mm

Chassis height [U]

1

Weight with packaging [kg(lb)]

8.9 (19.62)

Weight without packaging [kg(lb)]

5.62 (12.39)

Maximum power consumption [W]

High temperature 45°C (113°F), 100% traffic, and dual power modules: 181 W High temperature 45°C (113°F), 100% traffic, long-distance optical module, 100% fan speed, and dual power modules: 254 W

Typical power consumption [W]

149

Heat dissipation mode

Heat dissipation with fan, intelligent fan speed adjustment

Maximum heat dissipation [BTU/hour]

High temperature 45°C (113°F), 100% traffic, and dual power modules: 617.59 High temperature 45°C (113°F), 100% traffic, long-distance optical module, 100% fan speed, and dual power modules: 866.67

Typical heat dissipation [BTU/hour]

508.4

Power supply mode

Pluggable power supply

Input voltage range [V]

- AC input: 90–290 V AC; 45–65 Hz - High-voltage DC input: 190 V DC to 290 V DC - DC input: -38.4 V DC to -72 V DC

Rated input voltage [V]

- AC input: 100 V AC to 240 V AC; 50/60 Hz - High-voltage DC input: 240 V DC - DC input: –48 V DC to –60 V DC

Maximum input current [A]

The current specifications depend on the pluggable power modules in use. For details, see the related power module specifications.

Number of power slots

2

Number of card slots

0

Memory

4 GB

Flash memory

2 GB in total. To view the available flash memory size, run the display version command.

Redundant power supply

1+1 Pluggable AC and DC power modules can be used together in the same switch.

Types of fans

Pluggable

Noise at normal temperature (acoustic power) [dB(A)]

65

Noise at normal temperature (acoustic pressure) [dB(A)]

52

Airflow direction

Air intake from front, air exhaustion from rear (front-to-rear)

Storage temperature [°C(°F)]

-40°C to +70°C (-40°F to +158°F)

Long-term operating temperature [°C(°F)]

-5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)

Restriction on the operating temperature variation rate [°C(°F)]

When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F). When the QSFP-100G-ER4 optical module is used, the operating temperature ranges from -5°C to +40°C (23°F to 104°F).

Long-term operating relative humidity [RH]

5% to 95%, noncondensing

Storage altitude [m(ft.)]

0-5000 m (0-16404 ft.)

Long-term operating altitude [m(ft.)]

0-5000 m (0-16404 ft.)

MTBF [year]

62.27

MTTR [hour]

2

Availability

> 0.99999

Maximum number of physical ports on the entire device

30

Maximum number of 100GE ports

6 (with a license activated)

Maximum number of 40GE ports

6

Maximum number of 25GE ports

0

Maximum number of 10GE ports

24

Maximum number of GE ports

24

Maximum number of FE ports

0

100G optical interface

6

40G optical interface

6

10GE optical interface

24

USB

Supported

Console port

RJ45

Eth Management port

RJ45

Service port surge protection [kV]

-

Power supply surge protection

- AC power module configured: ±6 kV in differential mode, ±6 kV in common mode - DC power module configured: ±2 kV in differential mode, ±4 kV in common mode

RPS input

Not supported

PoE

Not supported
