2024 waterproof 4ch 720p mdvr kit Truck 4g gps wifi video monitoring dvr 4 channel mdvr
- Category: >>>
- Supplier: Shenzhen Citops Systems Co. Ltd.
Share on (1601279545910):
Product Overview
Description
Products Description
2024 waterproof 4ch 720p mdvr kit Truck 4g gps wifi video monitoring dvr 4 channel mdvr
Product features
* The interface can operate reliably and stably in complex environments
* Video encoding H.265, H.264 is optional
* Support 4G 、wifi and GPS functional modules
* Supports a 2.5-inch optional SSD hard disk
* Support two SD cards
* Rich peripheral interfaces
* Support external UPS battery life
* Waterproof dust-proof
* Video encoding H.265, H.264 is optional
* Support 4G 、wifi and GPS functional modules
* Supports a 2.5-inch optional SSD hard disk
* Support two SD cards
* Rich peripheral interfaces
* Support external UPS battery life
* Waterproof dust-proof
The product supports 4G+GPS, it is recommended to contact the customer for more information before placing an order.
Details Images
Item | parameters | ||
Audio and Video Inputs | video input | AHD：4ch 1080/25fps IPC：Scalable 1-4ch | |
audio input | 4ch audio input | ||
Audio and Video outputs | video output | Default 1-way CVBS output (VGA output optional) | |
speech output | 1ch audio output | ||
Audio and video parameter coding | video coding | H.264 Main Profile/H.265 | |
Resolution | 1080P/720P/D1 optional | ||
audio coding | Default G.726,G.711A optional | ||
Storage space | HDD | 1 2.5-inch SSD hard disk | |
SD | Support 2 SD card | ||
Wireless network | 4G | Supports 1 SIM card, optional: all major communication modules in the world | |
WIFI | 2.4/5.8G optional | ||
Locate mode | BD/GPS | Support for mixed positioning, speed detection, time synchronization | |
Interface | serial port | Support 1 RS232, 1 RS485, can be connected with external sensor | |
I/O | Support 2 level input | ||
Intercom | 1 special intercom handmark interface | ||
Physical Specifications | size | 154mm（L）*148mm（W）*39mm（H） | |
weight | NW：1.05kg GW：1.35kg（M32Hv-TGNE1-L as a standard） | ||
work environment | operating temperature | -20°C〜 +70°C | |
operating humidity | · 10%〜95%（No condensation） | ||
Other | operator schema | remote control、APP、WEB | |
· Gravity sensor | Built-in G-Sensor | ||
Enhanced Version Control | USB fire-proof box | Video backup special port | |
I/O | Add 2 level inputs, 2 analog inputs, and 2 alarm outputs | ||
network interface | Support external IPC, support hybrid NVR function | ||
