4ch H.265 4g Mdvr 1080p Camera Hdd Vehicle 3g Car Dvr Mobile Gps 4g Wifi Cmsv6 Mdvr
- Category: >>>
- Supplier: Shenzhen Citops Systems Co. Ltd.
Share on (1601279630140):
Product Overview
Description
Products Description
4ch H.265 4g Mdvr 1080p Camera Hdd Vehicle 3g Car Dvr Mobile Gps 4g Wifi Cmsv6 Mdvr series is a high-performance and highly scalable product specially developed for in-vehicle video surveillance and remote video surveillance. It adopts the bootstrap structure design of hard disk, high-speed processor NT98323 and embedded operating system, and integrates H.264/H.265 video compression, 4G network, GPS/BD positioning and other technologies in the front line of IT. Applicable to public security police, financial escort, long-distance passenger transportation, road patrol and other vehicles traveling monitoring field.
Product Advantages
* interface for stable and reliable operation in complex environments
* video encoding is H.265, H.264 optional
* supports 4G WIFI and GPS function module
* Supports 2.5-inch optional SSD/HDD hard drive
* supports one SD card
* rich peripheral interface
* supports external UPS battery life
* High Expandabilityvideo encoding is H.265, H.264 optional
* interface for stable and reliable operation in complex environments
* video encoding is H.265, H.264 optional
* supports 4G WIFI and GPS function module
* Supports 2.5-inch optional SSD/HDD hard drive
* supports one SD card
* rich peripheral interface
* supports external UPS battery life
* High Expandabilityvideo encoding is H.265, H.264 optional
Note:Order only include a 4/8ch mdvr with 4g+gps
Product Paramenters
Item | M51HV | M52HV | ||
Audio and Video Inputs | video input | AHD：4ch 1080P/25fps IPC：Scalable 1-4ch | AHD：4/8ch 1080P/25fps IPC：Scalable 1-4ch | |
audio input | 4ch audio input | 4ch audio input | ||
Audio and Video outputs | video output | Default 1-way CVBS output (VGA output optional) | Default 1-way CVBS output (VGA output optional) | |
speech output | 1ch audio output | 1ch audio output | ||
Audio and video parameter coding | video coding | H.264 Main Profile/H.265 | H.264 Main Profile/H.265 | |
Resolution | 1080P/720P/D1 optional | 1080P/720P/D1 optional | ||
audio coding | Default G.726,G.711A optional | Default G.726,G.711A optional | ||
storage space | HDD | 1 2.5-inch optional: SSD/HDD hard disk | 1 2.5-inch optional: SSD/HDD hard disk | |
SD | Support 1 SD card | Support 1 SD card | ||
wireless network | 4G | Supports 1 SIM card, optional: all major communication modules in the world | Supports 1 SIM card, optional: all major communication modules in the world | |
WIFI | 2.4/5.8G optional | 2.4/5.8G optional | ||
locate mode | BD/GPS | Support for mixed positioning, speed detection, time synchronization | Support for mixed positioning, speed detection, time synchronization | |
interface | USB | USB2.0 interface, support export data, external engineering treasure | USB2.0 interface, support export data, external engineering treasure | |
serial port | Support 2 RS232, 1 RS485, can be connected with external sensor | Support 2 RS232, 1 RS485, can be connected with external sensor | ||
I/O | 4 level inputs, 2 analog inputs, 2 alarm outputs | 4 level inputs, 2 analog inputs, 2 alarm outputs | ||
network interface | Support external IPC, support hybrid NVR function | Support external IPC, support hybrid NVR function | ||
· Intercom | 1 special intercom handheld mark interface | 1 special intercom handheld mark interface | ||
Physical Specifications | size | 176.9mm（L）*186.8mm（W）*54mm（H） | 176.9mm（L）*186.8mm（W）*54mm（H） | |
weight | NW：1.4kg GW：2kg（M51Hv-DGNE1-L as a standard） | NW：1.4kg GW：2kg（M52Hv-DGNE1-L as a standard） | ||
work environment | operating temperature | -20〜+70℃ | -20〜+70℃ | |
operating humidity | 8%〜90%（No condensation） | 8%〜90%（No condensation） | ||
Other | operator schema | remote control、APP、WEB | remote control、APP、WEB | |
· Gravity sensor | Built-in G-Sensor | Built-in G-Sensor | ||
