Automatic Duck Cattle Chicken Feed Pellet Machine Chicken Feed Pellet Mill Production Line
- Category: >>>
- Supplier: Zhengzhou Sinoder Indutech Machinery Co. Ltd.
Share on (1601279890917):
Product Overview
Description
Automatic Duck Cattle Chicken Feed Pellet Machine Chicken Feed Pellet Mill Production Line
Product Description
Brief introduction of animal feed pellet machine
1.Animal feed pellet machine , can process powder feed into pellet feed. It applies to feed process of pig, chicken, duck, goose, cow fish and so on.
2.It can be connected with small straw crusher and mixer, automatic stirring, automatic feeding,saving time and effort.
Raw material for pelleting animal feed pellet machine
-branches, wood waste, palm tree etc
--corn stalk, wheat straw, cotton stalk, husk, bean straw, dried grass, rice stalk etc
--peanut shell, rice shell, cotton shell, corn cob etc
Working principle
Structure : Vertical crushing mixer feeding mechanism (mainly by the suction and conveying type), crushing host, mix to bin, mixed host, discharging institutions, transmission mechanism etc.
This series crusher cabinet welded using high quality materials, feeding port, and grinder top in various forms of feeding structure suitable, hammer for symmetry.
Crusher work, material entered into the crushing chamber, in high speed rotating hammer blow and sieve under friction material gradually, has been shattered, and under the action of centrifugal and airflow. Through the bottom mouth. High efficiency and good performance. Applicable to feed, medicine, chemical industry, etc.
Application
1. It is used to produce pellet feed for pig, cattle, sheep, rabbit, chicken, duck, fish,etc.
2. It is suitable for small feed mill , and family farming, pig farm, chicken farm ans so on
3.It also can be used to process wood waste(residual sawdust,wood shavings,wood pellings,etc.)yard waste,farm waste(corn cobs,corn stalks,straw from plants,etc)and other residues biomass waste(bamboo crumbs,peanut shell,bagasse,alfalfa ).
Main technical parameter
Model | Power(kw) | Output(kg/h) | Size (mm) | Weight (kg) | Volume (m³) | Mixing Uniformity (CV%) | |
grinder | mixer | ||||||
500 | 7.5-11 | 3 | 500-700 | 2300*1050*2500 | 430 | 0.5 | ≥ 95 |
750 | 7.5-11 | 3 | 700-900 | 2350*1160*2600 | 460 | 0.75 | ≥ 95 |
1000 | 7.5-15 | 3-4 | 1000-1500 | 2400*1300*2900 | 540 | 1 | ≥ 95 |
1500 | 11-15 | 4 | 1500-2000 | 2798*1200*3020 | 800 | 1.5 | ≥ 95 |
2000 | 11-15 | 4 | 2000-2500 | 2800*1750*3100 | 1000 | 2 | ≥ 95 |
Company Information
Zhengzhou Sinoder Indutech Machinery Co., ltd (hereafter referred to as "Sinoder") is a joint-stock machinery manufacturing enterprise, integrating industrial scientific research, production and marketing. The company is located in the Industry Area Zone of Zhengzhou, China.
Packaging & Shipping
1.Waterproof packing with the international export standard by 20ft, 40ft, 40hp container.
2. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box.
Other Equipment will be packed by Color-Stripes Plastic Cloth.
3. Or as per customer's requirements.
Our Services
1)Designing and fabricating the products in accordance with the special requirements of the clients;
2) Providing construction and technology consultations or working out proper construction schemes for those new, special or difficult projects.
3)Checking products acceptance ahead of delivery;
4) Installing and testing the equipments;
5) Training the first-line operators on site;
6) Examining the equipment regularly;
7) Providing technical exchanging;
8) Providing maintenance for big item
FAQ
If you want to know more information , Pls to contact us
Tel: 0371 55933391 Mobile/wechat/whatsapp:+86 13643859200 Fax: 0371 55919082
