Products Description
Lutong 4WD LTB804 Mini Tractor with 60hp
- Max.traction force: 20KN
- Rated power: 80HP
* Adopt Xinchai diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency.
* Double-function clutch,10 inches, high transmission capacity, reliable, comfortable manipulation.
* Gearbox using 4 × 3 (1 +1) engaging sleeve, shuttle-type gearshift, there are 12 forward gears, 12 reverse gears, reasonable match between the gears, and have high efficiency.
* Independent power take off device, smooth transmission, large capacity, speed (540/760, 540/1000 r/min) for selection to meet the different operation requirements.
* Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save
energy.
* Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good.
* Adopt high pressure type lifting device, reliable, easy maintenance, multi-hydraulic output can be optioned.
* Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio.
* New streamlined appearance, generous, modern, fashion.
* Control levers can be mounted at side as optional, more convenient and comfortable.
Product Paramenters
Drive Type | / | 4x4 | ||
Overall Dimension L×W×H | mm | 4396×4396×2810 | ||
Wheel base | mm | 2195 | ||
Front wheel tread | mm | 1610 | ||
Rear wheel tread | mm | 1620-2020 | ||
Min. ground clearance | mm | 379 | ||
Min. steering radius | Unilateral brake | m | 4.2±0.3 | |
Not unilateral brake | m | 4.9±0.3 | ||
Min. operating weight | KG | 4090 | ||
Gearbox gears number | / | 16F+8R | ||
Speed | Forward | Kw/h | 1.58-33.69 | |
Reverse | Kw/h | 2.41-34.67 | ||
Engine | Model | / | LR4B5-23 | |
Rated power | Kw | 59 | ||
Rated speed | r/min | 2300 | ||
Tires spec. | Front tires | / | 11.2-24 | |
Rear tires | / | 16.9-34 | ||
Steering Type | / | Full hydraulic front wheels steering | ||
Max. lifting force | KN | 14.2 | ||
PTO | Type | / | Rear-mounted, Independent type | |
Speed | r/min | 760/1000 or 540/1000 | ||
Power | Kw | 51.2 | ||
Control type of ploughing depth | / | Height control & flotation control | ||
Max. traction force | KN | 18.6 | ||
Front / rear Ballast | KG | 270/470 | ||
