FANUC ARC Mate 100ID Welding Robot With MEGMEET Welder And Positioner for Welding Stainless Steel Sheet Components and Parts
- Category: >>>
- Supplier: Zhengzhou King Shine Auto Technology Co. Ltd.
Share on (1601280321700):
Product Overview
Description
Product Overview
FANUC ARC Mate 100ID Welding Robot With MEGMEET Welder And Positioner for Welding Stainless Steel Sheet Components and Parts
With ARC Mate 100ID Welding Robot, the hose pack- age is totally integrated into the upper arm and through the base of the robot. This means, all media necessary for arc welding, including power, welding wire, shield- ing gas and pressurized air is routed for maximized performance and energy efficiency. The ARC Mate 100ID Welding Robot delivers stable welding, excellent path accuracy, short cycle times and extended life expectancy of the hose package. Thanks to the integrated dressing, welding around cylindrical objects can be carried out without any stops and narrow spaces are more easily accessed.
Specification
Robot version | Reach (m) | Payload (kg) | Armload (kg) | ||
ARC Mate 100ID Welding Robot | 1.5 | 4 | 10 | ||
Number of axes | 6 | ||||
Protection | IP40 | ||||
Mounting | Floor, inverted | ||||
Controller | IRC5 Single Cabinet | ||||
Technical information
Electrical Connections | ||
Supply voltage | 380 V | |
Power consumption | ISO cube 0.6 kW | |
Physical | ||
Robot base | 300 x 300 mm | |
Robot weight | 170 kg | |
Environment | ||
Ambient temperature for mechanical unit | ||
During operation | +5° C (41° F) to + 45°C (113°F) | |
During transportation and storage | -25° C (-13° F) to +55° C (131° F) | |
During short periods (max. 24 h) | up to +70° C (158° F) | |
Relative humidity | Max. 95% | |
Safety | Double circuits with supervisions, emergency stops and safety functions. 3-position enable device | |
Emission | EMC/EMI shielded | |
Data and dimensions may be changed without notice. | ||
Axis movement | Working range | Axis max. speed |
Axis 1 rotation | +170° to -170° | 130°/s |
Axis 2 arm | +150° to -90° | 140°/s |
Axis 3 arm | +80° to -100° | 140°/s |
Axis 4 rotation | +155° to -155° | 320°/s |
Axis 5 bend | +135° to -135° | 380°/s |
Axis 6 * turn | +200° to -200° | 460°/s |
Performance
IRB 1520ID | |
Position repeatability | 0.05 mm |
Path repeatability | 0.35 mm |
Equipment Advantages
Wide Application | Aluminum, Stainless Steel, Carbon Steel, Copper，Silver, Titanium and Tin can be welded by fiber laser. |
Excellent welding seam & Reliable Quality | beautiful weld and no blackening, no spatter , Evenly no or very tiny deformation. vey Chinese Laser reactor quality has been improved in Chinese Market. The theoretical workstation life of laser reactor is about 100 thousand hours. |
Flexible installation | With a payload capacity of 4 kilograms and a reach of 1.5 meters, the highly compact ARC Welding Robot can be mounted in both floor and inverted position. This positioning flexibility offers short cycle times and a wide range of production possibilities. |
High reliability of equipment | 24 hours of continuous stable processing, to meet theneeds ofindustrialmass production and processing |
Lower labor costs | A general worker with zero welding experience can get started and complete professional welding work after just one day of simple training. Can save 2 welders, 1 ordinary worker and 2 professional welders |
Working range
Company Profile
KING SHINE is a manufacturer of automated welding, cutting, and handling robots, specializing in the production technology and equipment of automated welding and cutting for 20 years
We provide portable welding machines, automatic robot welding machines, automatic robot 3D cutting machines, pressure vessel specific welding machines, and special truck carriage specific welding machines. We have helped many factories with his welding process. Such as boiler/pressure vessel factories, truck factories H-beam factory and gate factory. We sincerely hope that our technology and experience can bring value to your business. We are ready for further discussion at any time.
We provide portable welding machines, automatic robot welding machines, automatic robot 3D cutting machines, pressure vessel specific welding machines, and special truck carriage specific welding machines. We have helped many factories with his welding process. Such as boiler/pressure vessel factories, truck factories H-beam factory and gate factory. We sincerely hope that our technology and experience can bring value to your business. We are ready for further discussion at any time.
