M9 Factory Cheap Price Plaster Projecting Self Leveling Automatic Dry Cement Sand Mortar Gypsum Plastering Station Sprayer

Share on (1601281365429):


Price:$1,900.00-2,000.00

Quantity:


Product Overview

Description





FULLY AUTOMATIC INTELLIGENT DESIGN PLASTERING MACHINE M9
A fully automatic plastering station machine is a comprehensive system designed to streamline the plastering process in construction projects. This type of machine integrates several functions, including mixing, transporting, and applying plaster, all with minimal human intervention. Here’s a detailed overview:

Key Components

1 Material Hopper:
Stores the raw plaster materials (e.g., gypsum, cement).
Often equipped with sensors to monitor material levels.
2 Mixing Unit:
Automatically mixes the plaster ingredients to achieve the desired consistency.
May include a water supply system for precise mixing ratios.
3 Pumping System:
Pumps the mixed plaster to the application nozzle.
Ensures consistent flow rates and pressure.
4 Application Mechanism:
Sprays or applies plaster onto walls and ceilings.
Can adjust to different patterns and thicknesses based on project requirements.
5 Control Panel:
User interface for programming and monitoring the machine.
Allows operators to set parameters such as mix ratios, flow rates, and application thickness.
6 Mobility Features:
Equipped with wheels or tracks for easy movement around the job site.
May include hydraulic lifts for adjusting height during application.

Advantages

1 Efficiency: Reduces the time needed for plastering large areas compared to manual methods.
2 Consistency: Delivers uniform application, minimizing imperfections and reducing the need for rework.
3 Labor Reduction: Requires fewer operators, which can lower labor costs and improve safety.
4 Material Savings: Precise mixing and application reduce waste of plaster materials.
5 Versatility: Can handle various types of plaster and surface conditions, making it suitable for diverse projects.

Applications

1 Residential Construction: Ideal for new builds and renovations.
2 Commercial Projects: Well-suited for large-scale commercial buildings and public infrastructure.
3 Industrial Settings: Used in warehouses and factories where speed and efficiency are crucial.


MODEL
M9
MAX PARTICLE SIZE
6MM
POWER
5.5KW(380V)
HOPPER VOLUME
115L
MAX FLOW RATE
30L/MIN
MAX STUFFING HEIGHT
900MM
MAX WORKING PRESSURE
30BAR
TOTAL WEIGHT
220KG
AIR COMPRESSOR POWER
3KW
SIZE
123*72*155CM


Product Description




Packing & Delivery




Company Profile




FAQ


1. Are you a manufacturer?
Yes, we are manufacturer and our factory have more than 20 years manufacturing experience.

2. Where is your factory?

Our factory is located in lianyungang city,jiangsu province, China. Welcome to visit us. We can also show you our factory
and production through video chat.

3. What’s your warranty?

The warranty of our products is 1 year, and we will always provide after sale service.

4. What’s your advantage?

As a factory with R & D capabilities, we can provide OED, OEM service, and also can guarantee delivery time and
competitive prices.

5. What kind of payment terms do you accept?

T/T, L/C at sight, Western Union, Cash etc. We also accept trade on Alibaba directly.
