Industrial Plastic Pulverizer Grinder Machine PP PVC PE Pulverizer Machine Plastic Crusher Machine
- Category: >>>
- Supplier: Shanghai Aultral Machinery Co. Ltd.
Share on (1601281453084):
Product Overview
Description
Overview
Plastic Pulverizer
Plastic Pulverizer is a rotor-type plastic mill, mainly used with the processing and grinding of heat-sensitive materials, can be processed and milled poly pvc-type materials and other materials such as powder processing, has a high yield, fine grinding, high efficiency and energy saving, environmental protection and other characteristics.
Products Description
Features：
1、This machine uses water circulation and air cooling, which is suitable for processing heat-sensitive materials.
2、This machine is made by the high-speed rotation of the spindle disc and the high-speed rotation of the fixed blade disc to make the materials entering the machine
High-speed movement and milling discs have a strong collision, cut into powder.
3、The movable knife and fixed knife are made of wear-resistant steel casting, after heat treatment, its high hardness, wear-resistant performance is particularly good.
4、This machine has a compact structure, small volume, as long as you open the door cover can be maintained, fully sealed, no dust spillage.
5, grinding coarse and fine adjustable, through the spindle nut adjustment washer can be.
6、This machine is equipped with air-fed discharging device to ensure uniform cooling of materials, cooling speed and other characteristics.
7、With relevant fan and dust removal device, no dust leakage.
2、This machine is made by the high-speed rotation of the spindle disc and the high-speed rotation of the fixed blade disc to make the materials entering the machine
High-speed movement and milling discs have a strong collision, cut into powder.
3、The movable knife and fixed knife are made of wear-resistant steel casting, after heat treatment, its high hardness, wear-resistant performance is particularly good.
4、This machine has a compact structure, small volume, as long as you open the door cover can be maintained, fully sealed, no dust spillage.
5, grinding coarse and fine adjustable, through the spindle nut adjustment washer can be.
6、This machine is equipped with air-fed discharging device to ensure uniform cooling of materials, cooling speed and other characteristics.
7、With relevant fan and dust removal device, no dust leakage.
Specifications
Model | MF-400 | MF-500 | SMF-600 | SMF-600 | |||
Diameter of cutter disc | 400mm | 510mm | 610mm | 785mm | |||
Motor power | 22KW | 37KW | 45KW | 90KW | |||
Feeding method | Automatic dosing with speed regulator, speed adjustable | ||||||
Capacity | 80-150kg/h | 150-200kg/h | 220-250kg/h | 400-450kg/h | |||
Powder size | 0-80mesh | ||||||
Blower | 4KW | 4KW | 4KW | 5.5KW | |||
Off fan | 0.75KW | 0.75KW | 0.75KW | 1.5KW | |||
Vibrating screen motor | 1.1KW | 1.1KW | 1.1KW | 1.5KW | |||
Vibrating feeder | 150KW | 200KW | 200KW | 500KW | |||
Blade Material | Special steel | ||||||
Weight | 1200kg | 1500kg | 1500kg | 2500kg | |||
Overall Dimension | 1800*1100*2500mm | 2000*1100*2800mm | 2000*1100*2800mm | 2500*1800*3100mm | |||
Main electrical appliances | Drexel | ||||||
Vibrating screen diameter | 800mm | 800mm | 1000mm | 1200mm | |||
Details Images
Company Profile
Why Choose Us
Expertise: Over 20 years of industry experience. we support OEM/ODM service.
Quality: High standards and innovative products.
Support: Comprehensive customer service and maintenance.
Sustainability: Eco-friendly practices and solutions.
Global Reach: Serving customers in over 50 countries.
Customer Focus: Dedicated to exceeding your expectations.
Packing&Shipping
FAQ
Q:How to choose a suitable machine meet your requirement?
A:Our technical consulting services can help, recommend the most suitable machine and program according to your needs, capacity,
site and other actual situation.
Q:How about the service?
A:We provide after-sales service, including on-site installation, commissioning equipment, guidance and training of operators etc. Make regular return visits to solve your equipment problems and optimize your equipment maintenance methods.
Q:How long is your delivery time?
A:Generally, it will be about 20-35 working days after deposit, which also will affected by the actual situation of the project.
Q:Which trade terms is available?
A:FOB, CFR,CIF, EXW and other terms based on your needs.
A:Our technical consulting services can help, recommend the most suitable machine and program according to your needs, capacity,
site and other actual situation.
Q:How about the service?
A:We provide after-sales service, including on-site installation, commissioning equipment, guidance and training of operators etc. Make regular return visits to solve your equipment problems and optimize your equipment maintenance methods.
Q:How long is your delivery time?
A:Generally, it will be about 20-35 working days after deposit, which also will affected by the actual situation of the project.
Q:Which trade terms is available?
A:FOB, CFR,CIF, EXW and other terms based on your needs.
