OceanStor Pacific 9550 Storage 2318169 OMXD30000 Optical Transceiver,SFP ,10G,Multi mode Module(850nm,0.3km,LC)
- Category: >>>
- Supplier: Shenzhen Hong Telecom Equipment Service Limited
Share on (1601282953957):
Product Overview
Description
Product Overview
New-Gen OceanStor 5310/5510/5610 Hybrid Flash Storage Systems
Hua wei's new generation of mid-range hybrid flash storage systems is designed to future-proof data centers.
Hua wei New-Gen OceanStor 5310/5510/5610 adopt Hua wei proprietary algorithms to efficiently deploy data across different media, using Solid-State Disks (SSDs) to accelerate mission-critical data. Comprehensive convergence and value-added features also deliver system efficiency and reliability, while built-in insight modules provide intelligent prediction capabilities.
Such features provide diversified storage services to users, making the systems purpose-built for finance, government,
manufacturing, education, healthcare, energy, and media entertainment sectors.
Hua wei New-Gen OceanStor 5310/5510/5610 adopt Hua wei proprietary algorithms to efficiently deploy data across different media, using Solid-State Disks (SSDs) to accelerate mission-critical data. Comprehensive convergence and value-added features also deliver system efficiency and reliability, while built-in insight modules provide intelligent prediction capabilities.
Such features provide diversified storage services to users, making the systems purpose-built for finance, government,
manufacturing, education, healthcare, energy, and media entertainment sectors.
Technical Specifications
Parameters | OceanStor 5310 | OceanStor 5510 | OceanStor 5610 | |||
Hardware Specifications | ||||||
Maximum Number of Controllers | 16 | 16 | 16 | |||
Maximum Cache (dual controllers, grows with the expansion of controllers) | 128 GB to 2 TB | 384 GB to 4 TB | 768 GB to 8 TB | |||
Supported Storage Protocols | FC, iSCSI, NFS, CIFS, FC-NVMe, NVMe over RoCE, NDMP, NFS over RDMA | FC, iSCSI, NFS, CIFS, FC-NVMe, NVMe over RoCE, FTP*, HTTP*, NDMP and S3*, NFS over RDMA | ||||
Front-End Channel Port Types | 8/16/32 Gbps FC/FC-NVMe, 1/10/25/40/100 Gbps Ethernet, and 25 Gbps NVMe over RoCE | |||||
Back-End Channel Port Types | 100 Gbps RDMA/SAS 3.0 | |||||
Maximum Number of Hot-Swappable I/O Modules per Controller Enclosure | 6 | 12 | ||||
Maximum Number of Front-End Host Ports per Controller Enclosure | 40 | 48 | ||||
Hard Disk Types | NVMe SSD, SAS SSD, SAS, NL-SAS | |||||
Software Specifications | ||||||
RAID Levels | RAID 5, RAID 6, RAID10*, and RAID-TP (tolerating the simultaneous failure of three disks) | |||||
Value-added software | SmartAcceleration, SmartThin, SmartQuota, SmartMulti-Tenant, SmartQoS, SmartVirtualization, SmartMigration, SmartCompression, SmartMobility*, SmartMove HyperSnap, HyperReplication, HyperClone, HyperMetro, HyperCDP, HyperLock, HyperEncryption, HyperDetect*, HyperLink*, CloudBackup*, NFS+ | |||||
Product Appearance
Device Attributes
PN | Model Number | Description |
02354SEN | 55V6-384GS25DACC+ | 5510 (2U,Dual Ctrl,SAS,AC\\240V HVDC,384GB Cache,4*(4*12Gb) SAS,25*2.5",SPE53C0225) |
02354SEL | 55V6-384GS12DACC+ | 5510 (2U,Dual Ctrl,SAS,AC\\240V HVDC,384GB Cache,4*(4*12Gb) SAS,12*3.5",SPE53C0212,Applicable to 1.2m-Depth Cabinets) |
02354SEP | 55V6-512GS25DACC+ | 5510 (2U,Dual Ctrl,SAS,AC\\240V HVDC,512GB Cache,4*(4*12Gb) SAS,25*2.5",SPE53C0225) |
02354SEM | 55V6-512GS12DACC+ | 5510 (2U,Dual Ctrl,SAS,AC\\240V HVDC,512GB Cache,4*(4*12Gb) SAS,12*3.5",SPE53C0212,Applicable to 1.2m-Depth Cabinets) |
02354SEQ | 55V6-384GN36DACC+ | 5510 (2U,Dual Ctrl,NVMe,AC\\240V HVDC,384GB Cache,4*100Gb RDMA,36*PALM,SPE63C0236,Applicable to 1.2m-Depth Cabinets) |
02354SER | 55V6-512GN36DACC+ | 5510 (2U,Dual Ctrl,NVMe,AC\\240V HVDC,512GB Cache,4*100Gb RDMA,36*Palm,SPE63C0236,Applicable to 1.2m-Depth Cabinets) |
0211G06G | RACK-42U-1 | 42U Storage AC Cabinet |
2121212 | PDU2K-32-1P-20/4 | AC Power Distribution Unit |
2121690 | PDU2000-3M | AC Power Distribution Unit |
02353VMG | P5U2N120HD35I | OceanStor Pacific 9550 Chassis(5U,120*3.5",2*64C 2.6GHz,4*480GB SSD,8*25GE,512GB Mem,DPE80000) |
02355HMU | P95X5U120HD35I64C384MON | OceanStor Pacific 9550 Chassis(5U,120*3.5",2*64C 2.6GHz,4*480GB SSD,8*25GE,384GB Mem,DPE80000) |
02312YKR | PAC2000S12-B1 | Server Platinum 2000W Version 2.0 AC power supply |
02312SXL | PDC2000S12-B1 | Server DC Power supply-PDC2000S12-B1-2000W-Air Cooling |
02314GVY | PAC2000S12-T2 | Titanium 2000W AC power supply |
02312BHY | BC5M02IBMB | Infiniband card-EDR(100Gb/s)-Dual port-QSFP28(without Optical module)-Half-height Half-length-Harf Handle bars-PCIE 3.0 x16 |
02312SFS | BC82ETHA | Ethernet Adapter,25GE/10GE(Hi1822),4-Port,SFP28(without Optical Transceiver),PCIE 3.0 x16,Half-height Half-length,Half Handle bars |
02315CLF | BC82ETHA01 | Ethernet Adapter,25GE/10GE(Hi1822),4-Port,SFP28(without Optical Transceiver),PCIE 3.0 x16,Half-height Half-length,Half Handle bars |
03029AQC | IBNICEHR2PT | InfiniBand card NIC-EDR/HDR-2 port -QSFP28-PCIE 4.0 x16 |
02314WWD | BC5M09ETHE | Ethernet Adapter,25GE,Dual-Port,SFP28(without Optical Transceiver),Half-height Half-length,Half Handle bars,PCIE 3.0 x8 |
02313WQK | BC5M02IBMB02 | Ethernet Adapter,100GE(ConnectX-5 VPI)-Dual port-QSFP28(without Optical module)-Half-height Half-length-Harf Handle bars-PCIE 3.0 x16 |
6411021 | IBNICEHR2PT | Other Server Accessories,InfiniBand card NIC-EDR/HDR-2 port -QSFP28-PCIE 4.0 x16-Vendor ID 15b3-Device ID 101b-2,Chinese and English doc |
03050AEH | 4SASS12G | 4 ports 4*12Gb SAS I/O module(MiniSAS HD) |
03050GXP | DV6-SMARTIO4*16FC-ML | 4 ports SmartIO I/O module(SFP+,16Gb FC) |
03050GXQ | SMART32GbFE | 4 ports SmartIO I/O module(SFP28,32Gb FC) |
03050GXR | DV6-SMARTIO4*10E-ML | 4 ports SmartIO I/O module(SFP+,10Gb ETH) |
03050GXS | DV6-SMARTIO4*25E-ML | 4 ports SmartIO I/O module(SFP28,25Gb ETH) |
03050GYE | DV6-LPU2*40ETH-ML | 2 ports 40Gb ETH I/O module(QSFP+,40Gb ETH) |
03050GYF | DV6-LPU2*100ETH-ML | 2 ports 100Gb ETH I/O module(QSFP28,100Gb ETH/for Front-End) |
03050GXV | DV6-4*10ETH-ML | 4 ports 10Gb ETH I/O module(RJ45) |
03050KLP | DV6-LPU4*1ETH-ML | 4 ports 1Gb ETH I/O module(RJ45) |
03050HYF | DV6-IPSEC4*10ETH-ML | 4-port 10Gb ETH I/O module (supporting IPSec encryption,SFP+,10Gb ETH) |
03050GXT | DV6-4*25RDMA-MLp | 4 ports 25Gb RoCE I/O module(SFP28,25Gb RoCE/for Front-End) |
03050GXU | Scale-25RDMA-M | 4 ports 25Gb RDMA I/O module(SFP28,Scale-out) |
03050KTM | DV6-4*25ROCE-SCont-Mlp | 4 ports 25Gb RoCE SmartContainer Connect I/O module |
02355NDK | L3-S-SSD480 | 480GB SSD SAS Disk Unit(2.5") |
02356FNY | L3-S-SSD960 | 960GB SSD SAS Disk Unit(2.5") |
02356FPB | L3-S-SSD1920 | 1.92TB SSD SAS Disk Unit(2.5") |
02356FPD | L3-S-SSD3840 | 3.84TB SSD SAS Disk Unit(2.5") |
02356FPG | L3-S-SSD7680 | 7.68TB SSD SAS Disk Unit(2.5") |
02352WFV | L3-L-NLSAS8TB | 8TB 7.2K RPM NL-SAS Disk Unit(3.5") |
02352WFX | L3-L-NLSAS10TB | 10TB 7.2K RPM NL-SAS Disk Unit(3.5") |
02352WQA | L3-L-NLSAS14TB | 14TB 7.2K RPM NL-SAS Disk Unit(3.5") |
02356GBH | L3-L-NLSAS16T | 16TB 7.2K RPM NL-SAS Disk Unit(3.5") |
02355SKK | L3-L-NLSAS20TB | 20TB 7.2K RPM NL-SAS Disk Unit(3.5") |
02355QEE | L3-L-SSD480 | 480GB SSD SAS Disk Unit(3.5") |
02356KLN | L3-L-SSD960 | 960GB SSD SAS Disk Unit(3.5") |
02356KLY | L3-L-SSD1920 | 1.92TB SSD SAS Disk Unit(3.5") |
02356KMR | L3-L-SSD3840 | 3.84TB SSD SAS Disk Unit(3.5") |
02356KNK | L3-L-SSD7680 | 7.68TB SSD SAS Disk Unit(3.5") |
02356MPV | L3-NVMe-SSD3840 | 3.84TB SSD NVMe Palm Disk Unit(7") |
02356MPY | L3-P-SSD7680 | 7.68TB SSD NVMe Palm Disk Unit(7") |
02353VAJ | SSDA-016T6I-A1 | 1.6TB SSD NVMe half-Palm Disk Unit(6") |
02355LYW | P-SSD-3.2T6P | 3.2TB SSD NVMe half-Palm Disk Unit(6") |
02355QPE | P-SSD-1.6T6P | 1.6TB SSD NVMe half-Palm Disk Unit(6") |
02356ETA | P-SSD-1.6T6P-1 | 1.6TB SSD NVMe half-Palm Disk Unit(6") |
02352TKE | DAE62525U2 | SAS Disk Enclosure(2U,AC\\240V HVDC,2.5",Expansion Module,25 Disk Slots,Without Disk Units,DAE62525U2-10) |
02352TKG | DAE62435U4 | SAS Disk Enclosure(4U,AC\\240V HVDC,3.5",Expansion Module,24 Disk Slots,Without Disk Units,DAE62435U4) |
02355XTC | DAE73625U2 | Smart NVMe Disk Enclosure(2U,AC\\240V HVDC,Palm,Expansion Module,100Gb RDMA,36 Disk Slots,Without Disk Units,DAE73625U2) |
02353SKX | NLSAS7.2H-8T5S-A1 | 8TB 7.2K RPM NL-SAS Disk Unit(3.5"),for High Density Disk Enclosure |
02352WQK | L3-L-NLSAS10THV5 | 10TB 7.2K RPM NL-SAS Disk Unit(3.5"),for High Density Disk Enclosure |
02352WQL | L3-L-NLSAS14THV5 | 14TB 7.2K RPM NL-SAS Disk Unit(3.5"),for High Density Disk Enclosure |
02356GUJ | L3-L-NLSAS16TH | 16TB 7.2K RPM NL-SAS Disk Unit(3.5"),for High Density Disk Enclosure |
02356ATG | L3-L-NLSAS20TH | 20TB 7.2K RPM NL-SAS Disk Unit(3.5"),for High Density Disk Enclosure |
02351CRU | STLZ59DME-75 | DAE17535U4 High Density Disk Enclosure(4U,3.5",AC,Dual SAS Expansion Module,1200W,75 Disks,without disk,12G baseboard) |
21240817 | EGUIDER05 | 4U Static Rail Kit(Direct delivery material) |
21240817-001 | EGUIDER05 | 4U Static Rail Kit(Direct delivery material) |
04151188-002 | IDSV2DKBM57 | Power Cable,3.0m,1mm^2,Black,HVDC Straight Female,227IEC53(RVV)1.0mm^2(3C) |
04151188-003 | CABLE5M-BLK-DC | Power Cable,5m,HVDC Straight Female,227IEC53(RVV)1.0mm^2(3C),NO |
14138471-002 | MPO-4DLC-8M3.5-L30 | Multi-Channel Optical Patchcord,MPO/PC,4DLC/PC,Multi-Mode,30m,8 Cores,0/1m,GJFH-8A1a.3(OM4),3.5mm,2mm,LSZH,25mm Ultra-Short MPO,Bending insensitive |
02354LBJ | SATA-6T3T-A11 | 6TB 7.2K RPM SATA Disk Unit(3.5") |
02354LBN | SATA-8T3T-A11 | 8TB 7.2K RPM SATA Disk Unit(3.5") |
02354LBK | SATA-10T3T-A11 | 10TB 7.2K RPM SATA Disk Unit(3.5") |
02354LKJ | SATA-16T3TRPM-A11 | 16TB 7.2K RPM SATA Disk Unit(3.5") |
02355YNP | P-SATA-20T3T-B3 | 20TB 7.2K RPM SATA Disk Unit(3.5") |
02355HWR | SATA-6T3T-B2 | 6TB 7.2K RPM SATA Disk Unit(3.5"),Dedicated Storage for Intelligent Video and Images |
02355HWQ | SATA-8T3T-B2 | 8TB 7.2K RPM SATA Disk Unit(3.5"),Dedicated Storage for Intelligent Video and Images |
02355HWP | SATA-10T3T-B2 | 10TB 7.2K RPM SATA Disk Unit(3.5"),Dedicated Storage for Intelligent Video and Images |
02355HWN | SATA-16T3T-B2 | 16TB 7.2K RPM SATA Disk Unit(3.5"),Dedicated Storage for Intelligent Video and Images |
02355YNN | P-SATA-20T3T-B4 | 20TB 7.2K RPM SATA Disk Unit(3.5"),Dedicated Storage for Intelligent Video and Images |
02356FWJ | P-SATA-24T3T-3 | 24TB 7.2K RPM SATA Disk Unit(3.5") |
