D size ER34615 3.6V Primary Lithium Battery ER34615 capacitor D Size 33600 for Gas meter water meters

Product Overview

Description

High Performance 3.6V D size ER34615 lithium battery





Battery model: ER34615H

Standard voltage: 3.6V;

Rated capacity: 19000mAh

Maximum continuous current: 400mA

Maximum pulse current: 800mA

Cell size: 14.5 x 50.5 (mm)

Working temperature: -55 C - + 5 C;

Storage temperature: -10 C - + 4;

Product characteristics: lithium thionyl chloride battery has high monomer voltage and is the most powerful battery in lithium battery. The discharge is smooth and the discharge curve is flat. Within 90% of the capacity, the working platform remains almost unchanged. The battery can work normally in the range of -55 C ~+85 C. The capacity at -55 C is about 50% of the normal temperature capacity. It shows excellent high and low temperature performance, the annual self discharge rate is less than 1%, and the storage life can reach more than 3 years. It is a very cost-effective battery.

Environmental protection: at present, the company has carried out the EU "ROSH" directive. The products have been certified by "SGS" and fully meet the requirements of the European customers for the environmental protection of the batteries.

Main uses: smart card table (water, electricity, gas meter), memory backup, computer support power, medical equipment, wireless communication, camera, camera, hand-held communication equipment, scientific research instrument, oil drilling, electric equipment, marine equipment etc. (can be added to the foot or wire according to the customer's request)

Matters of attention:

1. Because the battery is not recharged at a time, forced charging will cause leakage or damage to the equipment.

2. Battery "+ -" should be installed correctly in the direction specified by the equipment.

3. Prohibit short-circuit, heating, burning and disassembling batteries.



project	Company	Technical indicators	condition
Nominal voltage	V	3.6	Normal discharge
Nominal capacity	mAh	≥2000	Continuous discharge with  15 K Omega load
Instantaneous short  circuit current	mA	≥400	Time is less than 0.5 '
Open circuit voltage	v	≥2.7	All batteries
Storage temperature	℃	Normal atmospheric  temperature	-55-80℃
Standard weight	g	19	All batteries
