3 5TPD Automatic Vegetable Oil Refining Equipment for Coconut and Seed Used for Oil Production Line in Farm Industries
- Category: >>>
- Supplier: Henan Grain Buds Machinery & Equipment Co. Ltd.
Share on (1601284560952):
Product Overview
Description
Country of origin | Henan |
Payment method | L/C，D/A，D/P，T/T，Western Union，Money Gram |
Maritime port | qingdao port |
Whether to support the sample | No |
Process Characteristics
The process adopts continuous process of dehydration and de-soaping, which is suitable for small and medium-sized oil factories, and it is convenient to start and stop the machine freely and flexibly, which not only reduces the labor force, but also lowers the production cost. Adopt centrifuge separation, no need to precipitate, continuous separation, greatly reduce the working time, and the soap horn contains low neutral oil (less than 5%), improve the rate of oil yield, improve the efficiency and reduce production costs. Deodorization and deacidification adopts combined deacidification and deodorization tower, continuous operation, and deacidification adopts water vapor rate extraction, and thermosensitive decolorization, which does not hurt the neutral oil, and improves the quality and color of oil. Fatty acid trapping tower is added in the process, which recovers fatty acid, reduces air pollution and has no sewage discharge, and it is a proven process solution at present.
Main equipment features
Refining kettle and water washing kettle adopt vertical refining kettle, coil heating, slurry stirring, vertical direct drive of cycloid reducer, oil is heated uniformly, good tumbling, easy to operate. Centrifuge adopts self-cleaning disc centrifuge, high efficiency, less soap in oil, low oil in soap, high quality oil, continuous operation, reduce labor. Deacidification and deodorization adopts combined deacidification and deodorization tower, continuous operation, high efficiency, can eliminate the alkali refining and deacidification section, and the acid in the oil can be recovered, no soap emission, no sewage discharge, improve the economic efficiency, is currently the most feasible deacidification equipment.
Deacidification and degumming section
Gross oil from the oil extraction plant into the refining pot, open the stirrer (speed 65r/min), open the steam valve heating, oil temperature rose to 45 ℃, add 85% of the edible phosphoric acid, add the amount of oil weight of 0.1% -0.2%, continue to stir for 30min, and then add a good lye preparation, add a slow stirring, and at the same time to 1 ℃ per minute speed to 60 ℃, oil Saponin formation appears after the oil line off the heating valve, open the oil valve, open the oil pump will be pumped into the de-soaping centrifuge, adjust the pressure of the centrifuge, the separation of the saponin flow into the saponin tank, saponin pump by the saponin pump into the saponin storage tanks.
Dehydration and decolorization section
Clear oil under the action of vacuum into the decolorization pot, open the stirrer and steam valve to heat the grease, so that theoil dehydration, observation of the decolorization pot, to no water vapor overflow, add active white clay, add the amount of 2-5%of the weight of the oil (depending on the quality of the oil), decolorization temperature of 105-110 ° C, the decolorization time of 20-30 min, add the active white clay to open the decolorization pot after the oil drain valve, while opening the After addingactivated white clay, open the oil drain valve of decolorizing pot, and open the decolorizing oil pump, and then pump the oil into the filter, the decolorized oil will be filtered and separated, and the clean oil will be pumped into the clean oil tank.
Deacidification and deodorization section
The decolorized oil is pumped into the oil/oil heat exchanger through the rotor flow meter of the oil pump, and the oil from the deacidification tower is exchanged with the oil and then enters into the heat-conducting oil heater, where the temperature is heated up to 240-260℃ and enters into the top layer of the decolorization and deodorization tower, and then flows downward from the top through the oil distributor, and contacts with the direct vapors from the lower part of the decolorization tower against the flow, and then removes fatty acids from the oil in the high vacuum condition. The oil flows down to the thermal decolorization section, and after thermal decolorization, it is pumped out by the shielded pump and pumped into the oil/oil heat exchanger, exchanges heat with the decolorized oil from the clean oil tank, and then enters into the cooler and cools down to less than 70℃ and pumped into the finished oil tank
Q:Can this Oil pressing machine be customized?
A:Yes, we will try our best to meet your needs. If you have any special requirements, such as logo customization, please contact us. We will do our best to meet your needs as soon as possible.
Q:How can i trust your company and ensure to get the goods if i order from you?
A:We are the alibaba legitimate certification company, and we support payment by Alibaba platform to ensure your safty.
Q:Why should you buy from us not from other suppliers?
A:Our company set development, manufacturing, after-sales service in one, strong technical force and we have a professional manufacturing team. We warmly welcome you to visit our factory in the future!
Q:How can we pay?
A:We usually accept payment by T/T,L/C,Western Union or Alibaba platform.
Q:Are you manufacturer?
A:Yes, we are manufacturer with more than 20 years' experience, and can supply any spare parts for the machine.
Q:Does you have stock now?
A:Yes we have enough stock to meet your larger orders.
Q:Can you provide more information about production and quote the best price?
A:Of course, but first we have to confirm your needs. According to your needs, we will design the most suitable processing procedures for you. Once confirmed the machine, we will quote our best price.
A:Yes, we will try our best to meet your needs. If you have any special requirements, such as logo customization, please contact us. We will do our best to meet your needs as soon as possible.
Q:How can i trust your company and ensure to get the goods if i order from you?
A:We are the alibaba legitimate certification company, and we support payment by Alibaba platform to ensure your safty.
Q:Why should you buy from us not from other suppliers?
A:Our company set development, manufacturing, after-sales service in one, strong technical force and we have a professional manufacturing team. We warmly welcome you to visit our factory in the future!
Q:How can we pay?
A:We usually accept payment by T/T,L/C,Western Union or Alibaba platform.
Q:Are you manufacturer?
A:Yes, we are manufacturer with more than 20 years' experience, and can supply any spare parts for the machine.
Q:Does you have stock now?
A:Yes we have enough stock to meet your larger orders.
Q:Can you provide more information about production and quote the best price?
A:Of course, but first we have to confirm your needs. According to your needs, we will design the most suitable processing procedures for you. Once confirmed the machine, we will quote our best price.
