Model | BQPH-0101D | BQPH- 0102E | BQPH- 0404A | BQPH- 0505B | BQPH- 0510C | ||||
Nominal Output Power | 1200W | 1200W | 3600W | 5000W | 5000W | ||||
Surge Power | 2400W | 2400W | 5700W | 10000W | 10000W | ||||
Wave Form | Pure Sine Wave | ||||||||
Output Frequency and Voltage | 50/60Hz;208/220/230/240; L+N+PE | ||||||||
Battery Energy | 1280Wh | 2560Wh | 3840Wh | 5120Wh | 10240Wh | ||||
Battery Type | LiFePO4 | ||||||||
Cycle Life | ≥6000 Cycles | ||||||||
Max.PV Input Power(W) | 1000W | 1000W | 5000W | 6000W | 6000W | ||||
Max.PV Input Current(A) | 14A | 14A | 18A | 18A | 18A | ||||
MPPT Range & Operating Voltage(VDC) | 18-125V | 18-125V | 40-450V | 120-450V | 120-450V | ||||
Switch Time(ms) | 10(normal mode)/10(UPs mode) | ||||||||
Dimension | 475*290*373MM | 587*290*463MM | 524*350*485MM | 561*376*625MM | 561*376*947MM | ||||
Net Weight | 20KGS | 30KGS | 48KGS | 62KGS | 101KGS | ||||
Charging Temperature | 0~55℃ | ||||||||
Discharging Temperature | -20~55℃ |
