6.0m3 Bucket Large Wheel Loader LW700KN 7.0tons Well Received

6.0m3 Bucket Large Wheel Loader LW700KN 7.0tons Well Received

Category: >>>
Supplier: Caterbe Construction Equipment (Wuhan) Co. Ltd.

Price:$80,000.00 - $100,000.00

Quantity:

Product Overview

Description

Products Description

Lw700kn Wheel Loader 7 Tons Front End Loader Tractor Price (more models for sale)

High Firmness and Reliability:
The high quality diesel engine elaborately designed and manufactured especially for working conditions of construction machinery and sufficiently proved by the market is fitted with desert air filter to prolong the service life of filter element, improve the filtration accuracy,and reduce the wear of engine.

The heavy-duty design, thick plate structure, and robot welding ensure secure welds, high torsion resistance coefficient, and strong overload capacity and can endure the torsion and impact loads under all kinds of working conditions.

The bucket is made of high strength wear-resistant plates, with the reliability leading the industry. Drive parts of outstanding performances.

Two groups of double-row tapered roller bearings are adopted for the main hinge joints, featuring high carrying capacity and long service life.

The finite element analysis technology is adopted to reduce the stress concentration and eliminate the partial weaknesses so that the frame is resistant against impact and overload and handles with ease all kinds of overload conditions.

The innovated lubricating mode for sh aft sleeves and hinges and the oil groove lubricated shaft sleeves effectively improve the reliability and service life of hinges.

The bucket is completely made of high strength steel plates and the en-handed holder and sleeve type bucket teeth are adopted to improve the wear and impact resistance by more than 30%. The automatic robot welding is adopted to guarantee the quality and prolong the service life for each weld.

The high quality electro-hydraulically controlled parallel-shaft power shift transmission is adopted, with automatic gear shift switch (KD function) and four forward and three reverse gears. featuring advanced performances and high carrying capacity, it can completely meet the required power demand of the loader. The drive axle adopts heavy-duty wet type drive axle to realize higher reliability.

The front drive axle adopts three-section heavy-duty drive shaft to greatly improve the carrying capacity. In the enhanced construction machinery drive shaft structure, the drive shaft flanges are of DIN and SAE standard specifications, the bolt circle diameter of the fastening bolts is increased, and the high strength bolts are used for secure connection and reliable drive.

Product Paramenters

Description	Unit	Parameter value
Wheel base	mm	3450
Tread	mm	2360
Dump clearance at maximum lift	mm	3515
Reach at maximum lift	mm	1388
Height of hinge at maximum lift height	mm	4780
Working height(fully lifted)	mm	6560
Overall machine dimension L×W×H	mm	945534303630
Rated operating load	kg	7000
Bucket capacity	m³	6
Machine weight	kg	25500
Max.breakout force	kN	150
Max.horse power	kN	220
Lifting time of boom	s	≤6.5
Total cycle time	s	≤11
Minimum turning radius (at tire center)	mm	5920
Articulation angle	°	±40
Gradeability	°	28
Tyre size		26.5R25
EngineModel		/
Rated Power/Speed	kW/rpm	226/2100
