  • HW 98011310 S5735S L24T4X A1 24*10/100/1000BASE T ports, 4*XGE SFP ports optical network switch 24 port
HW 98011310 S5735S L24T4X A1 24*10/100/1000BASE T ports, 4*XGE SFP ports optical network switch 24 port
HW 98011310 S5735S-L24T4X-A1 24*10/100/1000BASE-T ports, 4*XGE SFP+ ports optical network switch 24 port
HW 98011310 S5735S-L24T4X-A1 24*10/100/1000BASE-T ports, 4*XGE SFP+ ports optical network switch 24 port
HW 98011310 S5735S-L24T4X-A1 24*10/100/1000BASE-T ports, 4*XGE SFP+ ports optical network switch 24 port
HW 98011310 S5735S-L24T4X-A1 24*10/100/1000BASE-T ports, 4*XGE SFP+ ports optical network switch 24 port
HW 98011310 S5735S-L24T4X-A1 24*10/100/1000BASE-T ports, 4*XGE SFP+ ports optical network switch 24 port

HW 98011310 S5735S L24T4X A1 24*10/100/1000BASE T ports, 4*XGE SFP ports optical network switch 24 port

Share on (1601289468767):


Price:

Quantity:


Product Overview

Description



Products Description


Item
Details
Description
S5735S-L24T4X-A1 (24*10/100/1000BASE-T ports, 4*XGE SFP+ ports, AC power)
Part Number
98011310
Model
S5735S-L24T4X-A1
First supported version
V200R020C10


Details Images




Specification


Item
Specification
Dimensions without packaging (H x W x D) [mm(in.)]
Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.7 in.)
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm
x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.)
Dimensions with packaging (H x W x D) [mm(in.)]
90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.)
Chassis height [U]
1 U
Chassis material
Metal
Weight without packaging [kg(lb)]
2.45 kg (5.4 lb)
Weight with packaging [kg(lb)]
3.34 kg (7.36 lb)
Typical power consumption [W]
32.7 W
Typical heat dissipation [BTU/hour]
111.58 BTU/hour
Maximum power consumption [W]
47.6 W
Maximum heat dissipation [BTU/hour]
162.42 BTU/hour
Static power consumption [W]
18.4 W
MTBF [years]
64.3 years
MTTR [hours]
2 hours
Availability
> 0.99999
Noise at normal temperature (acoustic power) [dB(A)]
39 dB(A)
Noise at normal temperature (acoustic pressure) [dB(A)]
27.2 dB(A)
Number of card slots
0
Number of power slots
0
Number of fans modules
1
Redundant power supply
Not supported
Long-term operating temperature [°C(°F)]
-5°C to +50°C (23°F to 122°F) (0 m to 1800 m altitude, non-industrial optical modules)
-5°C to +55°C (23°F to 131°F) (0 m to 1800 m altitude, industrial optical modules with transmission distances less than or equal
to 10 km)
Restriction on the operating temperature variation rate [°C(°F)]
When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the
altitude increases by 220 m (722 ft.).
The switch cannot be started when the ambient temperature is lower than 0°C (32°F).
The operating temperature ranges from -5°C to +45°C (23°F to 113°F) when optical modules with transmission distances greater than
or equal to 70 km are used.
Storage temperature [°C(°F)]
-40°C to +70°C (-40°F to +158°F)
Long-term operating relative humidity [RH]
5% to 95%, noncondensing
Long-term operating altitude [m(ft.)]
0-5000 m (0-16404 ft.)
Storage altitude [m(ft.)]
0-5000 m (0-16404 ft.)
Power supply mode
AC built-in
Rated input voltage [V]
AC input: 100 V AC to 240 V AC; 50/60 Hz
High-voltage DC input: 110 V DC to 250 V DC
Input voltage range [V]
AC input: 90 V AC to 264 V AC; 47 Hz to 63 Hz
High-voltage DC input: 88 V DC to 300 V DC
Maximum input current [A]
2 A
Memory
512 MB
Flash memory
512 MB
Console port
RJ45
Eth Management port
Not supported
USB
Not supported
RTC
Not supported
RPS input
Not supported
Service port surge protection [kV]
Common mode: ±7 kV
Power supply surge protection [kV]
±6 kV in differential mode, ±6 kV in common mode
Ingress protection level (dustproof/waterproof)
IP20
Types of fans
Built-in
Heat dissipation mode
Heat dissipation with fan, intelligent fan speed adjustment
Airflow direction
Air intake from left and front, air exhaustion from right
PoE
Not supported
Certification
EMC certification
Safety certification
Manufacturing certification
