Professional manufacturer Wet Concrete shotcrete robot/Robotic shotcrete machine with CE
- Category: >>>
- Supplier: Henan Yugong Machinery Equipment Co. Ltd.Henan Ltd.
Share on (1601293902591):
Product Overview
Description
Products Description
Application
Machine Advantage
Vehicle length | 7880mm |
Overall width | 2460mm |
Overall height | 3380mm |
Rated weight | 15.3T |
Minimum turning radius | 11.5M |
Maximum climbing gradient | ≥40° |
Engine power | 103KW |
wheelbase | 4100mm |
Front axle wheelbase | 1870mm |
Rear axle wheelbase | 1870mm |
1. Strong mobility, convenient transition, taking into account multiple faces; 2. Dual power system, strong adaptability and high reliability;
3. The manipulator has flexible action, large construction range and no construction blind area;
4. The dosage of accelerator is automatically matched with the concrete volume to reduce the consumption of accelerator;
5. Piston pumping system, the maximum injection volume is 30m3/h, and the comprehensive rebound rate is not greater than 15%;
6. The equipment is durable, technologically advanced, cost-effective and easy to maintain.
3. The manipulator has flexible action, large construction range and no construction blind area;
4. The dosage of accelerator is automatically matched with the concrete volume to reduce the consumption of accelerator;
5. Piston pumping system, the maximum injection volume is 30m3/h, and the comprehensive rebound rate is not greater than 15%;
6. The equipment is durable, technologically advanced, cost-effective and easy to maintain.
