condensing unit for freezer Screw Compressor Condensing Unit 3HP 10HP Industrial Cooling Compressor System

Product Overview

Description

condensing unit for freezer Screw Compressor Condensing Unit 3HP-10HP  Industrial Cooling Multiple Configurations Systems

Condensing Unit Model No.			LFFG-40	LFFG-50	LFFG-60	LFFG-70	LFFG-80	LFFG-90	LFFG-100
Applicable Temperature			-5℃~8℃
Refrigerant			R22
Power Supply			380V/50HZ
Compressor	Type		Semi-hermetic Screw Type
	Model		FVRH-40-120	FVRH-50-140	FVRH-60-160	FVRH-70-200	FVRH-80-230	FVRH-90-270	FVRH-100-300
	Energy adjustment		75%-100%		50%-75%-100%
Compresor cooling capacity and power	0℃Evaporative Temperature	(W)	104.2	136.8	181.5	199.3	248.4	271.7	294.1
		Cooling capacity
		(KW)	32.9	41.2	55.1	60	71	78.2	85.3
		Power
	-5℃Evaporative Temperature	(W)	85.7	112.5	149.4	164	204.4	223.6	242
		Cooling capacity
		(KW)	31.5	39.5	52.7	57.5	68	74.9	81.7
		Power
	-10℃Evaporative Temperature	(W)	69.8	91.8	121.8	133.7	166.8	182.5	197.5
		Cooling capacity
		(KW)	30.2	37.8	50.5	55	65.2	71.8	78.3
		Power
Joint	(diameter:mm)		54	66	76	76	76	108	108
	Suction joint
	(diameter:mm)		28	35	35	35	35	42	42
	Liquid Outlet Joint
	(diameter:mm)		42	42	54	54	54	66	66
	Suction joint
	(diameter:mm)		35	35	35	35	35	54	54
	Liquid Inlet Joint
Shape Size	A(mm)		1700	2150	2300	2300	2600	2600	2600
	B(mm)		670	680	770	770	850	850	850
	C(mm)		1100	1100	1250	1250	1300	1300	1300

Characteristics:
1Screw parallel refrigeration unit,compact structure and good-looking figure;
2.Scientific designs,steady air flow air,can fully exert heat-transfer capacity of the condensing unit;
3.Rational performance design,high energy efficiency;
4.Axial fan,good-looking figure,low processing noise level;
5.Convenient design for maintain(front board can be easily take down);
6.We keep in touch well with our supplier,to guarantee material quality and production lead time of every order.
7.Various brand of compressor for your choice;
8.Fits different refrigerant:R134A,R404A,R507A,R22.
