Bluesun Best Price 10KW Off grid solar inverter 2 mppt Low voltage 48V 120V/220V 50/60Hz Split Phase For Ecuador
- Category: >>>
- Supplier: Bluesun Outdoor Energy Co. Ltd.Bluesun Ltd.
Share on (1601294086907):
Product Overview
Description
INVERTER | ||
Rated Output Power | 10000W | |
Max.Peak Power | 20000W | |
Rated Output Voltage | 120Vac ，single-phase / 240Vac ，split-phase/three-phase, be paralleled | |
Load Capacity of Motors | 6HP | |
Rated AC Frequency | 50/60Hz | |
Waveform | Pure Sine Wave | |
Switch Time | 10ms（typical） | |
Parallel Capacity | 1~6 units | |
Output Mode | Off-grid (default) / Hybrid | |
BATTERY | ||
Battery Type | Li-ion / Lead-Acid / User Defined | |
Rated Battery Voltage | 48Vdc | |
Battery Voltage Range | 40 ～60Vdc | |
Max.MPPT Charging Current | 200A | |
Max.Mains/Generator Charging Current | 120A | |
Max.Hybrid Charging Current | 200A | |
PV INPUT | ||
Num. of MPPT Trackers | 2 | |
Max.PV Array Power | 5,500W+5,500W | |
Max.Input Current | 22A+22A | |
Max. Open Circuit Voltage | 500Vdc+500Vdc | |
MPPT Voltage Range UTILITY/ GENERATOR INPUT | 125~425Vdc | |
Input Voltage Range | 90 ～140Vac | |
Frequency Range | 50/60Hz | |
Bypass Overload Current | 63A | |
EFFICIENCY | ||
MPPT Tracking Efficiency | 99.9% | |
Max. Battery Inverter Efficiency | 92% | |
GENERAL | ||
Dimensions | 620*445*130mm | |
Weight | 27kg | |
Protection Degree | IP20 ，Indoor Only | |
Operating Temperature Range | -10~55°C, >45°C derated | |
Noise | <60dB | |
Cooling Method | Internal Fan | |
Warranty | 18 Months | |
COMMUNICATION | ||
Embedded Interfaces | RS485/CAN/USB/ Dry contact | |
External Modules（Optional） | Wi-Fi / GPRS | |
CERITIFACATION | ||
Safety | IEC62109-1, IEC62109-2,UL1741 | |
RoHs | Yes | |
EMC | EN61000-6-1, EN61000-6-3, FCC 15 class B | |
Payment Term | T/T | EXW | |||
FOB | |||||
CFR(C&F) | |||||
CIF | |||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
Paypal | Amount lower than 5000usd | ||||
West Union | |||||
Delivery Time | 7~10days after receiving payment for one container | ||||
