  • China Brand 240hp Bulldozer Crawler Bulldozer DH24 with Good Performance for sale
China Brand 240hp Bulldozer Crawler Bulldozer DH24 with Good Performance for sale
China Brand 240hp Bulldozer Crawler Bulldozer DH24 with Good Performance for sale
China Brand 240hp Bulldozer Crawler Bulldozer DH24 with Good Performance for sale
China Brand 240hp Bulldozer Crawler Bulldozer DH24 with Good Performance for sale
China Brand 240hp Bulldozer Crawler Bulldozer DH24 with Good Performance for sale
China Brand 240hp Bulldozer Crawler Bulldozer DH24 with Good Performance for sale
China Brand 240hp Bulldozer Crawler Bulldozer DH24 with Good Performance for sale

China Brand 240hp Bulldozer Crawler Bulldozer DH24 with Good Performance for sale

Share on (1601295456239):


Price:$78,000.00-99,800.00

Quantity:


Product Overview

Description







Products Description








TY160 Crawler Bulldozer 160HP With Spare Parts in Stock
The TY160 bulldozer which has excellent power, reliability and a long service life. Through the introduction of bulldozer
technology, at the same time absorb the advantages of D60A-8, The TY160 crawler type bulldozer has been developed by the domestic
design. The TY160 bulldozer adapt Weichai diesel engine which provides an output of 131 kW 160HP with excellent productivity.


Technical Characteristics:
* The appearance of the vehicle is based on optimization design.

* High engine power reserve, strong torque output, low fuel consumption, reliable controls.

* Hydraulically powered, automatic speed change, shift the gears without stop the vehicle.

* 3 elements, single stage and single phase torque converter features high efficiency and capacity.

* The updated hexahedral cab features outstanding visibility and good tightness.

* Using the triangle spline and the gear of crowned teeth and tip relief in the final drive to average the loads on the trans-mission components for more stability, prolong the lifetime.

* New blade is more durable and capacious.

* Alarming & monitoring system is reliable.

* Reliable manual- operated spool valve and external mounted valve for easy maintenance.





Product Paramenters


Name
Remarks
Specifications
Overall size of the machine（mm）
Straight shovel, traction rod
5128×3416×3120
Straight shovel, three toothed soil loosen
6215×3416×3120
The use quality of the whole machine（kg）
Straight shovel, traction rod
17100
Straight shovel, three toothed soil loosen
18700
Maximum traction power (kN)
148
Minimum turning radius (mm)
3100
Maximum climbing performance (°)
30
Minimum ground clearance (mm)
400
Average ground specific pressure (MPa)
0.065
Forward speed (km/h)
F1
3.1
F2
5.47
F3
9.07
Back speed (km/h)
R1
4.03
R2
7.12
R3
11.81
Tracked ground length (mm)
2430
Caterpillar center distance (mm)
1880
Production efficiency (m3/h)
30m distance
350
Engine
Model
Weichai WD10G178E25
type
Water cooling,straight line,four stroke,direct injection
The number of cylinder - bore * stroke (mm)
6－126×130
Rated power (kW)
131
Rated speed (r/min)
1850
Maximum torque (N.m/r/min)
830/1000～1200
Fuel consumption rate (g/kW.h)
≤210
Walking system
type
Swing type and balance beam suspension structure
Pitch (mm)
203.2
Number of wheels of single side belt
2
Number of single side pulley
unilateral and 2 bilateral
6
Crawler height (mm)
60
Working device
Straight shovel single shovel capacity (M3)
3.9
The maximum lifting height of the blade (mm)
1095
The maximum depth of soil cutting blade (mm)
545
The maximum tilt blade height (mm)
860
Type of soil looser
Three teeth
Three tooth looser tooth distance (mm)
950
Three tooth looser
Soil depth (mm)
572
Elevation (mm)
702
The three tooth scarifier weight (kg)
1621
