2024 Wholesale Best Price Growatt Shine Wifi Module Master
- Category: >>>
- Supplier: Wuxi Yifeng Technology Co. Ltd.Wuxi Ltd.
Share on (1601295658191):
Product Overview
Description
Product Description
Details
Datasheet | ShineMaster | ShineMaster4G |
Hardware Parameter | ||
Power adapter | Input: 100-240V, 50/60Hz AC Output 5V(+/-15%), 1A DC | Input: 100-240V, 50/60Hz AC Output 5V(+/-15%), 1A DC |
Power consumption | 2.5W | 2.5W |
Application Parameters | ||
Max.inverters connection | 32 | 64 |
Max. communication range | 500m | 500m |
Communication with inverters | RS485 (Modbus RTU protocol) | RS485 (Modbus RTU protocol) |
Communication with server | TCP(Modbus TCP protocol) | TCP(Modbus TCP protocol) |
Support network | Ethernet | 4G |
Data transmission interval | 5 Minutes | 5 Minutes |
Default server URL | server.growatt.com | server.growatt.com |
Supported servers | ShineServer | ShineServer |
General Data | ||
Dimensions(W/H/D) | 130/84/25mm | 130/84/25mm |
Weight | 180g | 180g |
Language | English | English |
Mounting options | Wall-mounted | Wall-mounted |
Ambient temperature range | -30°C~+60°C | -30°C~+60°C |
Degree of protection | IP30 | IP30 |
