XCR90-M Best Price Manufacture 90Ton Truck Cranes 90000kg All Rough Terrain Crane
Superb lifting performance
5-section boom of 48m. Two jib sections of 9.2m-16m , with 0°, 15° and 30° jib offset angles. Three boom telescoping modes, wider working radius and better application adaptability.
High performance
5-section boom of 48 m is the longest in the industry, the length of boom and jib can reach 61 m after jib is installed. Large displacement dual-variable plunger pump with confluent main valve adopting patented technology integrated, leads to improvement by 13% in operation efficiency. Large power engine + low speed large torque transmission system with hydraulic torque converter; acceleration performance is improved by 10%, the max. travel speed is 40 km/h and the max. grade ability is 70%.
Green and energy-saving
New energy-saving hydraulic system with double-variable pump combined with a valve-controlled load-sensing system. The fuel consumption under different working conditions can be reduced by 10%~15%. ECO energy-saving control, fuel consumption under different working conditions can be reduced by 5%-9%. Torque converter with lockup function, low speed large torque, high speed and high efficiency, and driving fuel consumption is reduced by 20%.
5-section boom of 48m. Two jib sections of 9.2m-16m , with 0°, 15° and 30° jib offset angles. Three boom telescoping modes, wider working radius and better application adaptability.
High performance
5-section boom of 48 m is the longest in the industry, the length of boom and jib can reach 61 m after jib is installed. Large displacement dual-variable plunger pump with confluent main valve adopting patented technology integrated, leads to improvement by 13% in operation efficiency. Large power engine + low speed large torque transmission system with hydraulic torque converter; acceleration performance is improved by 10%, the max. travel speed is 40 km/h and the max. grade ability is 70%.
Green and energy-saving
New energy-saving hydraulic system with double-variable pump combined with a valve-controlled load-sensing system. The fuel consumption under different working conditions can be reduced by 10%~15%. ECO energy-saving control, fuel consumption under different working conditions can be reduced by 5%-9%. Torque converter with lockup function, low speed large torque, high speed and high efficiency, and driving fuel consumption is reduced by 20%.
project | Unit | XCR90 | XCR120 | XCR100_U |
Maximum rated lifting moment | kN·m | 2840 | 3567 | 2840 |
Working range × maximum rated lifting capacity | m×t | 2.5×90 | 2.5*120 | 2.5*90.7(100USt) |
Main arm length | mm | 48000 | 50000 | 48000 |
jib length | mm | 17500 | 18300 | 17500 |
The quality of the whole machine is fully equipped | kg | 54923 | 77992 | 54846 |
Counterweight weight standard/fully equipped | kg | 10000/11500 | 16000/23000 | 10000/11500 |
Overall machine length | mm | 14468 | 15580 | 14468 |
Overall machine width | mm | 3280 | 3490 | 3280 |
Overall machine height | mm | 3898 | 3980 | 3898 |
Wheelbase | mm | 4000 | 4600 | 4000 |
Wheelbase | mm | 2520 | 2590 | 2520 |
approach angle | ° | 24 | 21 | 24 |
departure angle | ° | 24 | 22 | 24 |
Ground clearance | mm | 550 | 465 | 550 |
Outrigger span longitudinal × transversal | mm | 7800x7700 | 8450脳8400 | 7800x7700 |
engine model | - | SC9DK260.1G3 | SC9DF300.1G3 | B6.7 |
Engine rated power/speed | kW/(r/min | 192/2000 | 221/2200 | 209/2000 |
Main arm full extension time | s | 110 | 125 | 110 |
Amplitude start time | s | 55 | 55 | 55 |
Maximum rotation speed | r/min | 2 | 1.8 | 2 |
Maximum lifting speed of main roll: 4 layers without load | m/min | 145 | 145 | 145 |
maximum speed | km/h | 34.8 | 30 | 34.6 |
Theoretical maximum gradeability | % | 65 | 80 | 65 |
Minimum turning radius | m | 6.5 | 8.4 | 6.5 |
