Good Quality 10Kw 8Kw 5Kw 6Kw Split Phase Off Grid Inverter 120V 240V Parallel Support Hybrid Solar system
- Category: >>>
- Supplier: Sunwave Technology Co. Ltd.Sunwave Ltd.
Share on (1601296400798):
Product Overview
Description
Product Descriptions
Product Specifications
MODEL | SPI-8K-U | SPI-10K-U | ||
INVERTER OUTPUT | ||||
Rated Output Power | 8,000W | 10,000W | ||
Peak Power | 16,000W | 20,000W | ||
Rated Output Voltage | 120Vac,single-phase /240Vac,split-phase | |||
Load Capacity of Motors | 5HP | 6HP | ||
Rated AC Frequency | 50/60Hz | |||
Waveform | pure sine wave | |||
Switch Time | 10ms(typical) | |||
BATTERY | ||||
Battery Type | Li-ion /Lead-acid /User-defined | |||
Rated Battery Voltage | 48Vdc | |||
Battery Voltage Range | 40~60Vdc | |||
Max.PV Charging Current | 180A | 200A | ||
Max.Utility/Generator Charging Current | 100A | 120A | ||
Max.Hybrid Charging Current | 180A | 200A | ||
PV INPUT | ||||
Num.of MPPT | 2 | |||
Max.PV Array Power | 5,500W+5.500W | |||
Max.Input Current | 22A+22A | |||
Max.Open-circuit Voltage | 500Vdc+500Vdc | |||
MPPT Voltage Range | 125~425Vdc | |||
UTILITY /GENERATOR INPUT | ||||
Input Voltage Range | 90~140Vac | |||
Frequency Range | 50/60Hz | |||
Bypass Overload Current | 63A | |||
GENERAL | ||||
Dimensions | 620*445*130mm | |||
Weight | 27kg | |||
Protection Degree | IP20,indoor only | |||
Operating Temp.Range | -10~55℃,>45℃ derated | |||
Cooling Method | intelligent air cooling | |||
Warranty | 18 months | |||
COMMUNICATION | ||||
Embedded Interfaces | RS485 /CAN /USB /Dry contact | |||
External Module(optional) | Wi-Fi/GPRS | |||
