Zl50gn New Rc Front End 3ton Heavy Payload Wheel Loader

Price:$29,800.00

Quantity:

Item	VSL15	VSL20	VSL30	VSL50	VSL60
Rated Load(g)	1500	2000	3000	5000	6000
Bucket Capacity(m3)	0.6	1.3	1.7	3	3.3
Operating Weight(kg)	3000	5600	9600	17100	18200
Engine	QUANCHAI	CUMMINS	CUMMINS	CUMMINS	CUMMINS
Engine Model	482-52M22	4BT3.9-C100	6BT5.9-C130	6CTAA8.3-C215	6CTA8.3-C240
Rated Power(kw)	38	75	97	160	19
Rated Speed(r/min)	2200	200	2200	2200	2200
Dump Height(mm)	2850	3050\\3250	3100	3150	3448
Dump Distance(mm)	790	885	1006	1250	1249
Wheelbase(mm)	2100	2530	2660	3200	3200
Lifting,Lowering and Unloading Time(s)	13	11.3	9.15	10.95	10.8
Max. Breakout Force(KN)	43	48.87	127	170	204
Min. Turning Radius(mm)	3400	4500	5097	6640	7020
Overall Dimension(mm)	520016002550	625020902860	689024303070	792030503400	796530503470

1. The working device is optimized by computer, which makes the operation more portable and flexible and the movement more stable and reliable.

2. The rear-lift metal structure engine cover is adopted for the loader, which is durable and more convenient for maintenance.

3. The loader adopts high quality hydraulic piping and a reasonable layout, it also has high strength reserve gearbox, drive axle.

4. The loader has a heavy load frame and mature fixed-shaft transmission system, heavy-duty conditions overhaul cycle extended year-on-year.
