high quality mini 6ton tower crane SYT80 with top brand for sale
- Category: >>>
- Supplier: Liebty Machinery Technology (Hangzhou) Co. Ltd.Liebty Ltd.
Share on (1601305217844):
Product Overview
Description
Construction Machinery 8 Ton Topkit Tower Crane SYT80
Products Description
1. performance parameters and technical indexes reach both domestic and international advanced level.
• Max. jib length: 56m; Jib length under different assembling modes can decrease progressively by 5 meters and the Min. jib length is 31 meters.
• Max. lifting capacity 6t;
• Hoisting capacity at jib tip: 1t;
• Max. lifting moment: 80 t.m
• power: 25 kW; rope capacity: 380m;
• Slewing mechanism: S75C6R-130C12/16A; power: 7.5 kW
• Trolleying mechanism: T30FC60; power: 3kW
• Types of tower crane: stationary crane with embedded outriggers, stationary crane with embedded bolts, stationary crane with under-frame and mobile tower crane.
• Max. jib length: 56m; Jib length under different assembling modes can decrease progressively by 5 meters and the Min. jib length is 31 meters.
• Max. lifting capacity 6t;
• Hoisting capacity at jib tip: 1t;
• Max. lifting moment: 80 t.m
• power: 25 kW; rope capacity: 380m;
• Slewing mechanism: S75C6R-130C12/16A; power: 7.5 kW
• Trolleying mechanism: T30FC60; power: 3kW
• Types of tower crane: stationary crane with embedded outriggers, stationary crane with embedded bolts, stationary crane with under-frame and mobile tower crane.
Contact
Logan Zheng
Whatsapp/Wechat/Mobile: +86-18058317211
Email:logan@liebty.com
Company: Liebty Machinery Technology(Hangzhou) Co.,Ltd
Address: Room 208,Building 3, No.1866, Binxing Road, Changhe Street,
Bingjiang District, Hangzhou, Zhejiang, China
Bingjiang District, Hangzhou, Zhejiang, China
Specification
Model | SYT80 (T5710-6) | SYT80 (T6012-6) | SYT80 (T6013-6) | SYT80 (T6510-6) | SYT80 (T6510-8) | SYT100 (T6515-6) | ||||||
Country Standard | ||||||||||||
Power Frequency | 50Hz | 50Hz | 50Hz | 50Hz | 50Hz | 50Hz | ||||||
Power Voltage | 380V | 380V | 380V | 380V | 380V | 380V | ||||||
Operation | ||||||||||||
Free Standing Height | 40.5m | 40.5m | 46m | 43m | 43m | 46m | ||||||
Max Jib Length | 57m | 60m | 60m | 65m | 65m | 65m | ||||||
Max Lifting Capacity | 6T | 6T | 6T | 6T | 8T | 6T | ||||||
Max Lifting Moment | 80t·m | 80t·m | 80t·m | 80t·m | 80t·m | 100t·m | ||||||
The Max Height under Hook | 230m | 230m | 230m | 230m | 230m | 230m | ||||||
Tip Load at Max Jib Length | 1T | 1.2T | 1.3T | 1T | 1T | 1T | ||||||
Working Speed | ||||||||||||
The Power of Hoisting Mechanism | 24/24/5.4kW | 24/24/5.4kW | 24/24/5.4kW | 24/24/5.4kW | 30kW | 25kW | ||||||
The Power of Luffing Mechanism | 3.3/2.2kW | 3.3/2.2kW | 3.3/2.2kW | 3.3/2.2kW | 4.0kW | 4kW | ||||||
The Power of Slewing Mechanism | 7.5kW | 2*4.0kW | 2×5.5kW | 2×5.5kW | 2×5.5kW | 2×5.5kW | ||||||
The Speed of Hoisting Mechanism | 4.4-80r/min | 4.4-80r/min | 4.4-80r/min | 4.4-80r/min | 0-80r/min | 0-80r/min | ||||||
The Speed of Luffing Mechanism | 50/25r/min | 50/25r/min | 50/25r/min | 50/25r/min | 0-55r/min | 0-55r/min | ||||||
The Speed of Slewing Mechanism | 0-0.7r/min | 0-0.75r/min | 0-0.75r/min | 0-0.75r/min | 0-0.75r/min | 0-0.8r/min | ||||||
