Wildly Used 100 Ton Hydraulic Truck Crane XCT100_S 180 Diesel Multifunction
Wildly Used 100 Ton Hydraulic Truck Crane XCT100_S 180 Diesel Multifunction
Wildly Used 100 Ton Hydraulic Truck Crane XCT100_S 180 Diesel Multifunction
Wildly Used 100 Ton Hydraulic Truck Crane XCT100_S 180 Diesel Multifunction
Wildly Used 100 Ton Hydraulic Truck Crane XCT100_S 180 Diesel Multifunction
Wildly Used 100 Ton Hydraulic Truck Crane XCT100_S 180 Diesel Multifunction
Wildly Used 100 Ton Hydraulic Truck Crane XCT100_S 180 Diesel Multifunction

Wildly Used 100 Ton Hydraulic Truck Crane XCT100_S 180 Diesel Multifunction

Share on (1601320762069):


Price:$195,000.00-214,000.00

Quantity:


Product Overview

Description





Wildly Used 100 Ton Hydraulic Truck Crane XCT100_S 180 Diesel Multifunction


Products Description


1.Optimal power transmission system
Off-road specialized four-axle G-class chassis with low speed large torque power transmission system equipped, features higher
climbing capacity at lower speeds and job site transfer capacity at higher speeds, i.e. maximum grade ability of 45% and a maximum
travel speed of 90 km/h.

2.High grade electrical protection, more reliable operation
Improved electrical system reliability: waterproof and dustproof inserts, high temperature-resistant corrugated pipes, special wire harness closure sleeves and rubber sleeves are used, excellent dust protection, protection level up to IP67.

3.Every detail is crafted
New design of appearance details and improved decoration in driver's cab: cabs with high air tightness, artistic decoration, soft packaging instrument station, flameproof, antiskid and easy to clean floor mats, and hot press molding ceiling, new length/angle sensor with high precision and molding aluminum alloy junction box.

4.Consideration for humanized details, easier and faster operation
High-luminance LED outrigger working lamps, 40% increase in brightness, five-times improvement in service life; wide view winch monitoring mirror, safer winch operation.



Product Paramenters


Description
Unit
Parameter value
Overall length
mm
15600
Overall width
mm
3000
Overall Height
mm
3870
Wheel Base
mm
1920+3500+1420+1505
Track(front/rear)
mm
2449/2315
Front/Rear overhang
mm
2650/2765
Front/Rear extension
mm
1840/0
Total vehicle mass in travel configuration
kg
55000
Axle load
1st and 2nd Axle
kg
10000
3rd and 4th Axle
13000
5th Axle
9000
Engine Model
WP6G240E330
M906LA.E3A/2
WP12.430N
Engine rated power
kw/(r/min)
176/2300
190/2200
316/1900
Engine rated torque
N.m/(r/min)
860/1200-1700
1000/1200-1600
2060/1000-1400
Max. travel speed
km/h
90
Min. turning diameter
m
23
Min. ground clearance
mm
326
Max. grade ability
%
45
Approach angle
°
18
Departure angle
°
13
Braking distance (at 30 km/h, full load )
m
≤10
Oil consumption per 100km
L
70
Noise level at seated position
dB(A)
≤90
Exterior noise level
dB(A)
≤88
