Sinotruk Howo 6x4 20000Liters Sewage Suction Truck Toilet Waste Vacuum Suction Truck
- Category: >>>
- Supplier: Suizhou Daoyi Special Automobile Sales Co. Ltd.Suizhou Ltd.
Share on (1601321388224):
Product Overview
Description
Our factory can supply many different brands of sewage suction trucks,High pressure sewage suction and cleaning trucks,Fecal suction trucks .
For the sewage suction tank;
The truck chassis type mainly use 4x2 type,6x2type,6x4 type,8x4 type,also have 4x4 abd 6x6 all wheel drive type.,such as Dongfeng brand,Howo brand,Isuzu brand,Foton brand,Faw brand,Forland brand, Shacman brand,etc.
For the sewage suction tank;
The 4x2 type truck can mounted 5000liters to 14000liters capacity sewage tanks;
The 6x4 type truck can mounted 15000liters to 20000liters capacity sewage tanks;
The 6x4 type truck can mounted 15000liters to 20000liters capacity sewage tanks;
Product Description
Specification
Product name | Dongfeng 6X4 Sewage suction truck | |
Chassis parameters | ||
Drive mode | 6x4 | |
Chassis brand | Dongfeng Truck chassis | |
Front passenger | 2 | |
Engine | Yuchai 240hp , diesel type | |
Tyre | 10.00R20, 10pcs with 1 spare | |
Gearbox | 9 forward,2reverse,manual operated | |
Steering wheel | Left hand drive | |
Emission standard | Euro 3 Emission | |
Wheelbase(mm） | 4750+1350 | |
Max.Speed(Km/h) | 95 | |
Gross weigh/G.V.W(kg) | 25000 | |
Curb weight(kg) | 17000 | |
Air Conditioner | A/C | |
Up-body parameters | ||
Overall dimension(mm) | 10000x2550x3850 | |
Capacity of tank body | 20000 liters | |
Color | White | |
Diameter of suction tube | Φ100mm | |
Suction depth | > 8 m | |
Vacuum pump | type: Vane pump Pumping speed: 318 m3/h Rated speed: 1300rpm | |
Body Configuration | ||
1. The sewage tank has a volume of 20 cubic meters and is made of high-quality WISCO steel plates. The wall thickness is 8 mm and a wave-proof plate is reasonably designed in the middle of the tank. 2. Install china brand water circulation pump 3. Install an anti-overflow valve and a stainless steel filter on the vacuum pipe (to prevent impurities from entering the pump) 4. A seismic pressure gauge with a diameter of 100 is installed at the position of the sewage suction four-way valve, which can resist vibration in the working environment and reduce the pulsation effect of the medium pressure. 5. A 100mm sewage suction port, a 600mm hydraulic sewage outlet at the rear, and a 100mm sewage outlet 6. The tank has a lifting and self-unloading function, and the tail drain port can be opened hydraulically with a locking device. 7. The tank top design platform is equipped with a protective fence and 2 tank mouths are installed to facilitate feeding and cleaning the tank from the top. | ||
Packing & Delivery
Packing:Nude packing and covered with wax.
Shipping:Normally carried by bulk carriers or ro-ro ship,container transport is also available if the dimension is suitable.
Shipping:Normally carried by bulk carriers or ro-ro ship,container transport is also available if the dimension is suitable.
Company Profile
FAQ
Q1: I want to transport the truck by container, is it ok?
A: Yes, it is ok .The specific needs depend on the size of the vehicle. Generally, small trucks can be shipped with container, and large trucks can be shipped with bulk cargo ship.
Q2:How about your product quality?
A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.
Q3:How about the delivery time?
A:It depends on the product you ordered and quantity you need,usually produce one unit truck only need 25days.
A: Yes, it is ok .The specific needs depend on the size of the vehicle. Generally, small trucks can be shipped with container, and large trucks can be shipped with bulk cargo ship.
Q2:How about your product quality?
A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.
Q3:How about the delivery time?
A:It depends on the product you ordered and quantity you need,usually produce one unit truck only need 25days.
