OEM ODM 55 65 75 86 Inch Video Conference Classroom Teaching Infrared Touch screen TV Digital Smart Board Interactive Whiteboard

Share on (1601323059231):


Price:$260.00-380.00

Quantity:


Product Overview

Description



Products Description




















Product Paramenters


Screen Parameters
Size
65 inch
75 inch
86 inch
98 inch
Touch Type
Infrared touch
Touch Points
20 points
Input
Finger, Touch pen
Screen Surface
4mm Tempered Glass
Response Time
8 ms
Display Ratio
16:9
Display Size (mm)
1428x804mm
1650x9928mm
1895x1066mm
2159x1214mm
Resolution
3840 (H) x 2160 (V) , 4K screen
Pixel Pitch (mm)
0.372x0.372
0.429x0.429
0.4935x0.4935
0.5622x0.5622
Refresh Rate
60Hz
60Hz
60Hz
60Hz
Color Brightness
1.07B (10 bit)
Color Gamut
72%
Contrast Ratio
4000:1
1100:1
1200:1
1200:1
Viewing Angle
178° (H/V)
Backlight
DLED
Screen Brightness
350 cd/sqm
350 cd/sqm
350 cd/sqm
350 cd/sqm
Lifetime
>50000 Hours
Interface
HDMI in
3
USB 2.0
3
Touch x2
HDMI out
1
USB 3.0
3
VGA in x1
Audio in
1
SPDIF
1
RS232 x1
Audio out
1
RJ45 in
1
WIFI
Version
802.11 a/b/g/n/ac
Operating Frequency
2.4GHz / 5GHz
Operating Distance
0-12m
Remark
Realize this function through the wireless  module SI02
Power
Current
2.5A
3.0A
5.0A
7.5A
Input Voltage
AC100-240V, 50/60Hz
Power Consumption
250W
300W
500W
750W
Standby Power Consumption
<0.5W
Environment Factory
Operating Temperature
0℃~40℃
Operating Humidity
10%~90% RH
Storage Temperature
-20℃~60℃
Storage Humidity
10%~90% RH
Android System
System Version
Android 14.0
CPU
8-core A55, Mali G52*4
Main Frequency
1.2GHz
RAM
8G
ROM
128G
Windows 10/11 System
CPU
Intel core i3 / i5 / i7 (optional)
Memory
4G / 8G / 16G (optional)
Hard Disk
128G / 256G / 512G (optional)
Size
Product Size
149X90X9cm, 38KG
171x103x9cm, 53KG
196x117x10cm, 70KG
225x133x10cm, 102KG
Packing Size
165x105x20cm, 50KG
188x119x21cm, 66KG
213x133x21cm, 89KG
248x149x38cm, 136KG
Quantity of containers (pcs) 20'GP/40'GP/40'HQ
79 /183 /197
59/ 137/ 148
53/ 123/ 133
20/ 47/ 50


What Is an Interactive Smart Board?
An interactive smart board is a large display, usually wall-mounted, that connects to a computer and projector or has a built-in screen. The board acts as both a computer monitor and a whiteboard. Users can interact with the content on the screen using their fingers, a stylus, or other tools. This makes it a highly versatile and engaging way to present information, brainstorm ideas, or teach lessons.

How Does It Work?
1. Connection and Setup:
- An interactive smart board is connected to a computer and often to the internet.
- Content from the computer is projected onto the board, or the board itself has a display screen that doesn’t need an external projector.
- The smart board uses touch detection technology, like infrared or capacitive touch, to sense user input.
2. Interactivity:
-Touch and Gesture Control:** Users can write, draw, or interact with content directly on the board using gestures. For example, you can swipe to turn pages, pinch to zoom, or use your hand to move objects around.
-Writing and Annotations:** You can use a stylus or finger to write or draw on the board. The smart board software often lets you save these notes, share them digitally, or convert handwritten text into typed text.
- Multimedia Integration:** You can easily display videos, images, and websites, making presentations dynamic and engaging. Users can also annotate over videos or images to emphasize important details.
3. Software Features:
- Many smart boards come with built-in software designed for specific uses, like teaching, business meetings, or creative design. These programs can include pre-made templates, lesson plans, and collaboration tools.
- Features like screen sharing allow multiple devices to connect, making it easy for participants to share their screens and contribute to the discussion.
