Digging Holes Screw Drill Hydraulic Earth Auger For Excavator
$1,800.00-2,000.00
Yuchai Brand New 280kN. M Torque Rotary Drilling Rig Ycr280e Heavy Work Hydraulic Rotary Drill Rig
- Category: >>>
- Supplier: Zhengzhou Komatco Industrial Equipment Co. Ltd.Zhengzhou Ltd.
Share on (1601331675313):
Product Overview
Description
Overview
Contact
If you have any question, feel free to contact me.
I'm always ready to help.
Products Description
Yuchai YCR280 280kW Top Engine Brand Low Fuel Consumption
1. Equipped with imported brand cu-mins QSM11 engine, which meets the third-stage emission standards of national regulations, Rexroth pump, valve system, special chassis for rotary drilling rigs and special load-sensitive hydraulic system, flow distribution is more reasonable; equipped with imported motors, reducers and other cores Hydraulic components have higher reliability and stability, and the performance of the whole machine is better.2. The new structure power head, multi-level shock absorption, can be equipped with the power head protective cylinder drive, to perform full protective cylinder operation, and adapt to the increasingly stringent quality and environmental protection requirements of pile foundation construction. At the same time, it is equipped with efficient soil dumping function, which improves construction efficiency.
3. It can be widely used in construction fields such as municipal administration, highways, railway bridges, large buildings,
high-rise buildings, etc., for efficient drilling of hard rock.
4. Using segmented power control, select the appropriate engine working capacity according to the specific working conditions, reduce the working intensity of the engine and reduce fuel consumption.
5. Intelligent automatic idle speed function. After the whole machine has no operation for the set time, the engine will
automatically switch to the idle speed state with double protection, improving fuel economy.
6. The main winch adopts single-layer double-folded line structure technology, which completely avoids the problem of the main winch wire rope biting and abrasion, and improves the service life of the wire rope.
7. Adopt the latest Yuchai design language, powerful modeling and novel painting; based on ergonomics cockpit, it is fully
functional and easy to operate; excellent human-computer interaction interface, easy to operate, and the engine code can be inquired on the display interface.
8. Multi-channel camera monitoring makes it easy to observe the construction conditions of the drilling rig and improve
construction safety.
9. The impact hoist can be selected to realize the impact function, which highly reflects the characteristics of one machine with multiple functions and multiple functions.
Product Paramenters
Engine type | Cu-mins QSF3.8 |
Power/ revolution | 268kW2100pm |
Deployment speed (margin) | 400m |
Track shoe width | 800mm |
Traction | 520KN |
The maximum out torque | 285Nm |
Power head revolution | 6-30rpm |
The maximum pressure increased | 220KN |
The maximum pullout force | 275kN |
Pressurizing oill cytinder stroke | 5000mm |
Main winch | |
The maximum lfting force | 70kN |
The maximum lifting speed | 59/min |
Steel wire diameter | O18mm |
Awiliary winch | |
Lifing force of the first layer | 15kN |
The maximum lifting speed | 50n/min |
Steel wire diameter | φ12mm |
Front inclination angle of mast | 5° |
Left and right inclinations of mast | ±4° |
The maximum working pressure of system | 32MPa |
The maximum dilling diameter | 1200mm |
The maximum dilling depth | 80m/54m (6 sections friction type/4sections machine lock type) |
Weight at working state | 90t |
Weight at trnsporting state(Remove the rotating device) | 70t |
Weight at transporting state(Remove the drilling bucket) | 57t |
The standard configuration | φ508-6x14.5m Friction rod |
Optional configuration I | φ508-4x14.5m Machine lock lever |
