Motorcycle bearings and Electric Fan NTN 62212 2RS1 Deep Groove Ball Bearings Chrome Steel Rodamiento
- Category: >>>
- Supplier: Timson Power Technology (shanghai) Co. Ltd.Timson Ltd.
Share on (1601332355175):
Product Overview
Description
Product Description
The NTN 62212-2RS1 is a deep groove ball bearing with rubber seals on both sides, providing protection against contaminants and helping to retain lubrication.
Key Features:
Type: Deep groove ball bearing
Seals: 2RS1 means that this bearing is sealed with rubber seals on both sides, offering better protection from dirt, moisture, and other external contaminants.
Dimensions:
Bore diameter (d): 60 mm
Outer diameter (D): 110 mm
Width (B): 22 mm
Bearing Design:
Deep Groove Ball Bearing: This design enables the bearing to carry both radial and axial loads in both directions. It is known for its versatility and ability to handle high-speed rotation with low friction.
Seals (2RS1): The rubber seals prevent contaminants from entering the bearing and help maintain proper lubrication, which extends the bearing’s service life, especially in harsh environments.
Common Applications:
Electric motors (including those in home appliances and industrial machinery)
Automotive applications (e.g., wheel hubs, alternators)
Conveyors
Pumps
Industrial machines
Fans and compressors
Advantages:
Protection: The rubber seals enhance the bearing’s reliability by keeping debris and moisture out.
Smooth operation: Offers low friction for efficient performance at higher speeds.
Durability: The sealed design contributes to a longer service life, even under difficult conditions.
Key Features:
Type: Deep groove ball bearing
Seals: 2RS1 means that this bearing is sealed with rubber seals on both sides, offering better protection from dirt, moisture, and other external contaminants.
Dimensions:
Bore diameter (d): 60 mm
Outer diameter (D): 110 mm
Width (B): 22 mm
Bearing Design:
Deep Groove Ball Bearing: This design enables the bearing to carry both radial and axial loads in both directions. It is known for its versatility and ability to handle high-speed rotation with low friction.
Seals (2RS1): The rubber seals prevent contaminants from entering the bearing and help maintain proper lubrication, which extends the bearing’s service life, especially in harsh environments.
Common Applications:
Electric motors (including those in home appliances and industrial machinery)
Automotive applications (e.g., wheel hubs, alternators)
Conveyors
Pumps
Industrial machines
Fans and compressors
Advantages:
Protection: The rubber seals enhance the bearing’s reliability by keeping debris and moisture out.
Smooth operation: Offers low friction for efficient performance at higher speeds.
Durability: The sealed design contributes to a longer service life, even under difficult conditions.
Specification
Designation | Principal dimensions | dynamic | static | Reference speed | Limiting speed | ||||
d/mm | D/mm | B/mm | C/kn | Co/kn | r/min | r/min | |||
6314 | 70 | 150 | 35 | 111 | 68 | 9 500 | 6 300 | ||
6314 N | 70 | 150 | 35 | 111 | 68 | 9 500 | 6 300 | ||
6314 NR | 70 | 150 | 35 | 111 | 68 | 9 500 | 6 300 | ||
6314-2RS1 | 70 | 150 | 35 | 111 | 68 | 3 000 | |||
6314-2Z | 70 | 150 | 35 | 111 | 68 | 9 500 | 5 000 | ||
6314-RS1 | 70 | 150 | 35 | 111 | 68 | 3 000 | |||
6314-Z | 70 | 150 | 35 | 111 | 68 | 9 500 | 6 300 | ||
6211-2Z | 55 | 100 | 21 | 46.2 | 29 | 14 000 | 7 000 | ||
6211-2ZNR | 55 | 100 | 21 | 46.2 | 29 | 14 000 | 7 000 | ||
6211-RS1 | 55 | 100 | 21 | 46.2 | 29 | 4 300 | |||
6211-Z | 55 | 100 | 21 | 46.2 | 29 | 14 000 | 9 000 | ||
6211-ZNR | 55 | 100 | 21 | 46.2 | 29 | 14 000 | 9 000 | ||
62211-2RS1 | 55 | 100 | 25 | 43.6 | 29 | 10 000 | 4 300 | ||
62311-2RS1 | 55 | 120 | 43 | 71.5 | 45 | 3 800 | |||
6311 | 55 | 120 | 29 | 74.1 | 45 | 12 000 | 8 000 | ||
6311 M | 55 | 120 | 29 | 74.1 | 45 | 12 000 | 11 000 | ||
6311 N | 55 | 120 | 29 | 74.1 | 45 | 12 000 | 8 000 | ||
62306-2RS1 | 30 | 72 | 27 | 28.1 | 16 | 6 300 | |||
63006-2RS1 | 30 | 55 | 19 | 13.3 | 8.3 | 8 000 | |||
6306 | 30 | 72 | 19 | 29.6 | 16 | 20 000 | 13 000 | ||
6306 N | 30 | 72 | 19 | 29.6 | 16 | 20 000 | 13 000 | ||
6306 NR | 30 | 72 | 19 | 29.6 | 16 | 20 000 | 13 000 | ||
6306-2RS1 | 30 | 72 | 19 | 29.6 | 16 | 6 300 | |||
6306-2RZ | 30 | 72 | 19 | 29.6 | 16 | 20 000 | 11 000 | ||
6306-2Z | 30 | 72 | 19 | 29.6 | 16 | 20 000 | 11 000 | ||
6304-2Z | 20 | 52 | 15 | 16.8 | 7.8 | 30 000 | 15 000 | ||
6304-2ZNR | 20 | 52 | 15 | 16.8 | 7.8 | 30 000 | 15 000 | ||
6304-RSH | 20 | 52 | 15 | 16.8 | 7.8 | 9 500 | |||
6304-Z | 20 | 52 | 15 | 16.8 | 7.8 | 30 000 | 19 000 | ||
6304-ZNR | 20 | 52 | 15 | 16.8 | 7.8 | 30 000 | 19 000 | ||
4206 ATN9 | 30 | 62 | 20 | 26 | 20.8 | 17 000 | 9 500 | ||
4306 ATN9 | 30 | 72 | 27 | 41 | 30 | 16 000 | 8 500 | ||
6006 | 30 | 55 | 13 | 13.8 | 8.3 | 28 000 | 17 000 | ||
6006 N | 30 | 55 | 13 | 13.8 | 8.3 | 28 000 | 17 000 | ||
6006 NR | 30 | 55 | 13 | 13.8 | 8.3 | 28 000 | 17 000 | ||
6006-2RS1 | 30 | 55 | 13 | 13.8 | 8.3 | 8 000 | |||
6006-2RZ | 30 | 55 | 13 | 13.8 | 8.3 | 28 000 | 14 000 | ||
6006-2Z | 30 | 55 | 13 | 13.8 | 8.3 | 28 000 | 14 000 | ||
Packing & Delivery
Packing:
1, Universal packing.
2, nsk ntn EXPLO DIMSEN Packing.
3, Customized Packing.
4, Original brand packing. Contact us for more pictures.
1, Universal packing.
2, nsk ntn EXPLO DIMSEN Packing.
3, Customized Packing.
4, Original brand packing. Contact us for more pictures.
Delivery:
We usually send goods by sea or by air freight depends on the weight and volum of your pakcage, such as UPS, Fedex, DHL, TNT, EMS,etc. If buyer has designated forwarder, we can also send goods to them directly based on buyer's requirement.
We usually send goods by sea or by air freight depends on the weight and volum of your pakcage, such as UPS, Fedex, DHL, TNT, EMS,etc. If buyer has designated forwarder, we can also send goods to them directly based on buyer's requirement.
How long will it take to ship to my country?
If deliver by air express such as DHL, UPS, FEDEX, It will takes about 4-9 working days to arrive. If deliver by sea, It usually
takes about 30 to 45 working days to arrive.
What is the shipping cost?
The shipping cost depens on the gross weight and delivery address.
As for customized bearings, you can contact us for the exact shipping cost.
As for the RTS products, the shipping cost will be calculated by system automatically. you can see it on product page.
If deliver by air express such as DHL, UPS, FEDEX, It will takes about 4-9 working days to arrive. If deliver by sea, It usually
takes about 30 to 45 working days to arrive.
What is the shipping cost?
The shipping cost depens on the gross weight and delivery address.
As for customized bearings, you can contact us for the exact shipping cost.
As for the RTS products, the shipping cost will be calculated by system automatically. you can see it on product page.
Payment:
We accept T/T (Bank Wire), Trade Assurance through alibaba.com, Western Union, Money Grame, Paypal, L/C. Buyer can pay in USD, AUD, CAD, SGD, EUR, GBP, HKD, JPY and cash.
If you have any further question, please feel free to contact us.
We accept T/T (Bank Wire), Trade Assurance through alibaba.com, Western Union, Money Grame, Paypal, L/C. Buyer can pay in USD, AUD, CAD, SGD, EUR, GBP, HKD, JPY and cash.
If you have any further question, please feel free to contact us.
