Product Overview
Description
Can be customized lithium LFP battery pack | ||||
Mechanical | Cell & Method | LFP, 96S2P | ||
Dimension(L*W*H) | 1780mm x 720mm x 345mm | |||
Weight | 625KG | |||
Electrical Characteristics | Rated Capacity | 200Ah | ||
Min Capacity | 200Ah | |||
1C Discharge Capacity | ＞ 100% Rated Capacity | |||
Discharge Capacity @ -20℃(-4℉) | ＞ 70% Rated Capacity | |||
Norminal Voltage | 307.2V | |||
Energy | 61.4kWh | |||
Internal Impedance(@ 1000Hz.) | ≤200 mΩ | |||
Cycle Life | ＞3000 Cycles @ 0.5C 80% DOD | |||
Months Self Discharge | ≤ 5% @ 25℃(77℉) | |||
Efficiency of Charge | >99% @ 0.5C | |||
Efficiency of Disharge | >98% @0.5C | |||
Standard Charge | Max Charge Voltage | 350.4V | ||
Charge Current | 0.5C,100A | |||
Max Charge Current | 200A | |||
Standard Discharge | Standard discharge Current | 0.5C, 100A | ||
Max Discharge Current | 300A | |||
Discharge Cut-off Voltage | 240V | |||
Environmental | Charge Temperature | 0 ℃ to 45℃(32℉ to 113℉) @ 65±20%Relative Humidity | ||
Discharge Temperature | -20℃ to 60℃(-4℉ to 140℉) @ 65±20%Relative Humidity | |||
Storage Temperature | ≤ 1 Month, -20℃ to 60℃(-4℉ to 140℉) @ 65±20%Relative Humidity | |||
≤ 6 Month, -20℃ to 30℃(-4℉ to 80℉) @ 65±20%Relative Humidity | ||||
Product Description
Features:
1. Lifepo4 battery technology, 307.2V 200AH, 96S2P.
2. 40KW continue discharge, 80KW max discharge for 10 seconds.
3. Smart BMS integrated in the battery pack with CAN communication.
4. Short circuit/ Over current/ Over voltage/ Over temperature protection/SOC/SOH.
5. Strong steelcase with high strength.
6. Liquid cooling system on request.
7. Precharging.
1. Lifepo4 battery technology, 307.2V 200AH, 96S2P.
2. 40KW continue discharge, 80KW max discharge for 10 seconds.
3. Smart BMS integrated in the battery pack with CAN communication.
4. Short circuit/ Over current/ Over voltage/ Over temperature protection/SOC/SOH.
5. Strong steelcase with high strength.
6. Liquid cooling system on request.
7. Precharging.
144V 100Ah lithium battery | ||
Battery Type | ZL144100 | |
Capacity | 100Ah @25℃ | |
Voltage | 144v | |
Weight | 130.5kg | |
Working Voltage | 120v - 168v | |
Battery power: 14.4 kWh | ||
330V 100Ah Lithium battery | ||
Battery Type | ZL330100 | |
Cpacity | 100Ah @25℃ | |
Voltage | 330v | |
Weight | 276kg | |
Working voltage | 276V - 386.4V | |
Battery power: 33.12 kWh | ||
614v 100Ah lithium battery | ||
Battery Type | ZL614100 | |
Capacity | 100Ah @25℃ | |
Voltage | 614.4v | |
Weight | 558kg | |
Working Voltage | 480v - 700.8v | |
Battery power: 61.44 kWh | ||
1): Are you manufacturer or simply trading company?
Re: We are manufacturer, and we sincerely welcome you to visit our factory!
2): Can I get a lower price if I order large quantities?
Re: Yes, cheaper prices with more bigger size orders.
3): Do you offer charger for battery?
Re: Yes, we do. If you also need charger, please mention it when sending inquiry, kindly note that our charger cost is not
included in the battery cost.
4): How about your company intelligence?
Re: ISO9001 certification, China Hi-tech company, 10 million battery assurance, 8 patents, Almost all products are MSDS, UN38.3,
IEC62133, CB,etc certificated.
5): When you ship my order?
Re: Normally 5-10days after receiving your payment, but it can be negotiated based on order qty and production schedule.
6): How about the quality guarantee period?
Re: Two year!
Re: We are manufacturer, and we sincerely welcome you to visit our factory!
2): Can I get a lower price if I order large quantities?
Re: Yes, cheaper prices with more bigger size orders.
3): Do you offer charger for battery?
Re: Yes, we do. If you also need charger, please mention it when sending inquiry, kindly note that our charger cost is not
included in the battery cost.
4): How about your company intelligence?
Re: ISO9001 certification, China Hi-tech company, 10 million battery assurance, 8 patents, Almost all products are MSDS, UN38.3,
IEC62133, CB,etc certificated.
5): When you ship my order?
Re: Normally 5-10days after receiving your payment, but it can be negotiated based on order qty and production schedule.
6): How about the quality guarantee period?
Re: Two year!
