F6600M XPON ONU GPON ONT 4GE LAN 1PORT 2.4G/ 5.8G Dualband Model AX3000 WIFI Optical Fiber Equipment
- Category: >>>
- Supplier: Xiamen OuXinda Intelligent Technology Co.Xiamen Co.
Share on (1601345421151):
Product Overview
Description
Parameters | F6600M |
Dimensions (H x W x D) | 40 x 185 x 120 mm (without external antenna and pads) |
Weight (Without Power Adapter) | Approximately 400 g |
Operating Temperature | 0–40°C |
Operating Humidity | 5–95% RH (non-condensing) |
Power Adapter Input | 100–240 V AC, 50/60 Hz |
System Power Supply | 11–14 V DC, 1.5 A |
UNI | 4 x GE, 1 x POTS, 1 x USB, 2.4G/5G Wi-Fi 6 |
NNI | XPON |
Maximum Power Consumption* | 18 W |
Antenna | External antenna |
Installation Mode | Desktop |
XG-PON Port | • SC/UPC • Class N1/N2a/E1 • Receiver sensitivity: –28 dBm • Wavelengths: US 1260–1280 nm, DS 1575–1580 nm • Wavelength Blocking Filter (WBF) • Flexible mapping between the GEM port and TCONT • SN/Password/SN + Password/Bi-directional authentication based on OMCI • Upstream and downstream FEC • SR-DBA and NSR-DBA • 2.5 Gbit/s upstream, 10 Gbit/s downstream |
Ethernet Electrical Port | • Ethernet port-based VLAN tags and tag removal • 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission • QinQ VLAN • Limit on the number of learned MAC addresses • MAC address learning • Auto port speeds (10/100/1000 Mbit/s) |
POTS Port | • Maximum REN: 4 • G.711A/μ, G.729a/b and G.722 encoding/decoding • T.30/T.38/G.711 fax mode • DTMF • Emergency calls (with the SIP protocol) |
WLAN | • IEEE 802.11 b/g/n/ax (2.4G) • IEEE 802.11 a/n/ac/ax (5G) • 2 x 2 MIMO (2.4G) • 2 x 2 MIMO (5G) • Antenna gain: 5 dBi • WMM/Multiple SSIDs/WPS • 2.4G and 5G concurrency • Air interface rate: 574 Mbit/s (2.4G), 2.402 Gbit/s (5G) • Beamforming • Band steering • DL OFDMA • DL MU-MIMO • 1024 QAM • 160 MHz frequency bandwidth • WPA3 |
USB Port | • USB 2.0 • FTP-based network storage • File/Print sharing based on SAMBA • DLNA function |
Power Saving | COC V7 |
Q1: Are you a factory or a trading company?
A1: We are a professional production of all kinds of communication equipment and consumables communication factory, has more than
10 years of history.
Q2: Do you accept OEM service?
A2: Yes, we do. Custom designs are also accepted.
Q3: Can I try it for free? How long is the trial?
A3: Samples are available, but not free. The sample fee depends on the quantity and item you choose and can be refunded once the
official order is fulfilled. Samples take about 10-20 days.
Q4: What if we can't meet your minimum order quantity?
A4: We also accept small trial orders. Please feel free to contact us and we will be happy to help you.
Q5: How do you guarantee quality?
A5: We have a professional QC team, in the production process and before shipping quality inspection, and passed BSCl,RoHS,
iso9001.fcc. International quality product certification.
Q6: What are your delivery items?
A6: We can express, air and sea. We accept EXW,FOB,DDU,DAP, etc.
You can choose the most convenient and economical way.
A1: We are a professional production of all kinds of communication equipment and consumables communication factory, has more than
10 years of history.
Q2: Do you accept OEM service?
A2: Yes, we do. Custom designs are also accepted.
Q3: Can I try it for free? How long is the trial?
A3: Samples are available, but not free. The sample fee depends on the quantity and item you choose and can be refunded once the
official order is fulfilled. Samples take about 10-20 days.
Q4: What if we can't meet your minimum order quantity?
A4: We also accept small trial orders. Please feel free to contact us and we will be happy to help you.
Q5: How do you guarantee quality?
A5: We have a professional QC team, in the production process and before shipping quality inspection, and passed BSCl,RoHS,
iso9001.fcc. International quality product certification.
Q6: What are your delivery items?
A6: We can express, air and sea. We accept EXW,FOB,DDU,DAP, etc.
You can choose the most convenient and economical way.
