Turbine oil coalescence separation oil purifier with turbine oil filtration

Product Overview

Description

Meiheng Economic And Reliable YJF Coalescence Separation Oil Purifier Oil Filtration Machine





Type	Overall Diameter  (mm)			Flow Rate (L/h)	Power (KW)	Input Power
	L	W	H
YJF-30	1550	650	1100	1800	0.75	380V 50HZ (can be changed)
YJF-50	1600	800	1150	3000	1.1
YJF-80	1650	1000	1250	4800	2.2
YJF-100	1750	1100	1300	6000	2.2
YJF-150	1850	1200	1400	9000	5.5
YJF-200	2000	1250	1550	12000	7.5
YJF-300	2050	1350	1650	18000	15



Principle:

    Inside of coalescence & separation machine there are filter cores for coalescence and separation and separation. Emulsified oil flows from the inside of coalescence core to the outsid. The water contained in the oil has gone through filtration, breaking emulsion and coalescence. Emulsified water and free water gradually flow from outside of the separation core to the inside. The separation core is made of special material. The drops of water on the ourside gather together until they settle down and the water is removed.



Characteristics:

1. It combines precision filtration and dewatering, effectively breaks emulsion water and separates free, water emulsified water from oil.

2.  High precision of filtration, big capacity for pollutant filtering cores can be used for a long time, highly effective dewatering.

3.  Keep the physical and chemical character of oil.

4.  No heating required, vacuum pump and fast speed centrifugation, low energy cost.

5. Pressure automatic control protection and filtration core invalidation alarm makes the operation safe and simple.

6. It can effectively remove free water and solid pollutants contained in the oil. According to red different requirements, it can process online or other ways.





Q1,:What’s the application scope of Screw press machine ?

A1: It is widely applied in wastewater treatment in industrial, chemical, municipal and so on.

Q2: How can I get the bottom price?
A2: The price marked is already the best price for you.

Q3: How long will it take to receive my product?
A3: In general, it will take you 10-15 days to get it.

Q4: What payment methods can I use?

A4: Currently, you can pay via L/C,Western Union,T/T(bank transfer),Paypal, MasterCard

Q5: Customer Service:

A5: Please contact us any time when you have questions or problems upon our products. Your inquiry will be replied within 24 hours.
