  • ISUZU Used Small Refrigerated Trucks Double Cabin 4X2 Rear Door For Refrigerated Truck Body LHD/RHD Refrigerator Truck
ISUZU Used Small Refrigerated Trucks Double Cabin 4X2 Rear Door For Refrigerated Truck Body LHD/RHD Refrigerator Truck
ISUZU Used Small Refrigerated Trucks Double Cabin 4X2 Rear Door For Refrigerated Truck Body LHD/RHD Refrigerator Truck
ISUZU Used Small Refrigerated Trucks Double Cabin 4X2 Rear Door For Refrigerated Truck Body LHD/RHD Refrigerator Truck
ISUZU Used Small Refrigerated Trucks Double Cabin 4X2 Rear Door For Refrigerated Truck Body LHD/RHD Refrigerator Truck
ISUZU Used Small Refrigerated Trucks Double Cabin 4X2 Rear Door For Refrigerated Truck Body LHD/RHD Refrigerator Truck
ISUZU Used Small Refrigerated Trucks Double Cabin 4X2 Rear Door For Refrigerated Truck Body LHD/RHD Refrigerator Truck
ISUZU Used Small Refrigerated Trucks Double Cabin 4X2 Rear Door For Refrigerated Truck Body LHD/RHD Refrigerator Truck

ISUZU Used Small Refrigerated Trucks Double Cabin 4X2 Rear Door For Refrigerated Truck Body LHD/RHD Refrigerator Truck

Share on (1601351870320):


Price:$11,000.00-13,800.00

Quantity:


Product Overview

Description



































































































































































































Truck Body Details


Truck Body

Key Features


Cold King Refrigerator Truck is made of all-closed sandwich structure panels, which is made by special technology to vacuum form

complete panels. We use free-Freon molding polyurethane foam as inner insulation materials. The internal and external coverings

are integral FRP sheets (fiberglass reinforced polyester), therefore, homogeneous construction (without any metallic

reinforcements).


Truck Body Outer Size


4.3m(L)x2.0m(W)x2.1m(H)


Truck Body Inner Size


4.13m(L)x1.83m(W)x1.89m(H)


Roof/Floor Panel


105mm Thickness


Side Wall Panel


85mm Thickness


Front Wall Panel


85mm Thickness


Rear Door Panel


85mm Thickness


Panel Structure


All Closed Sandwich


Panel Insulation


FRP + PU Foam + FRP


Side Door Quantity


None, Optional


Side Door Location


None, Optional


Side Door Type


Single/Double Opening


Side Door Size


Customized


Rear Door Type


Full Size Double Opening Rear Door, Right Hnad Rear Door Open First


Multi-Temperature

System Type


None, Optional


Front Space Temp.


-25C


Rear Space Temp.


-25C


Partition Wall Panel


None


Partition Wall Door


None


Multi-Temperature Pressure Relief Ventilation


None


Mulit-Temperature Adjusting Ventilation System


None


Truck Body Flooring


Heavy Duty Aluminum Alloy T Type Airflow Flooring


Cargo Control System


None, Optional


Ceiling Light


2 (Two) Sets of 12/24V Multi-Voltage LED


Marker Light


2 Sets Of White LED On Front;

2 Sets Of Red LED On Rear


Ceiling Light Switch


1 (One) Set of Automatic Time-Delayed 12/24V Multi-Voltage Switch


Insulating Curtain


European Standard -40C PVC Strip Curtain System For Rear Doors


Refrigeration Unit Service Ladder


Stainless Steel


Refrigeration Unit Service Platform


None, Optional


Airflow Flooring


Heavy Duty Aluminum Alloy T Type Airflow Flooring


Rear Door Assembly


Stainles Steel Rear Door Frame With Stainless Steel Lock Sets & Stainless Steel Hinges.


Refrigeration Unit


Refrigeration Unit Brand


ATOP


Refrigeration Unit Model


AT-KLC430


Refrigeration Unit Type


Truck Engine Driven, Split


Refrigerant


HFC R404a


Airflow Volume


1,600m3/h


Refrigeration Capacity

(+30C Ambient/Road )


2,000W (@ -18C)

3,300W (@ 0C)


Refrigeration Capacity

(+30C Ambient/Standby)


Available Optional


Defrost


Automatic Hot Gas


Compressor


Number of Cylinders


6


Max. Recommended Speed


2,400rpm


Model/Type


5H16 Swash Plate Type


Displacement


162cc


Optional Items


Hydraulic Tail Lift


Aluminium Alloy/Steel Platform Hydraulic Tail Lift Are Available


Cargo Control System


Smart & customized cargo Loading control system


Meat Hanging System


Heavy duty stainless steel meat hook & aluminum alloy rail for rapid & stable meat transportation


Roll carts


Roll carts for rapid and efficient loading, delivery and unloading goods. It was customized made according to inner dimension &

configuration of refrigeration truck body.


Multi-Temperature Partition


Multi-temperature purpose longitudinally moveable, insulated transverse partition wall









Q: How can we guarantee quality?
A:Always a pre-production sample before mass production;
Always final Inspection before shipment;

Q:What can you buy from us?
A:Truck trailer,Semi trailer,Tanker trailer,low bed trailer,Cement bulker


Q: How long I can receive?
A:Kindly let us know your destination port, usually Asian countries seashipping time 3-20 days.
Europe countries 30-45 days. Africa countries 40- 60 days. American countries 25-40 days.

Q:Can we customize?
A:Yes, we are factory and provide OEM service. Please send your trailer specification for our confirmation.




Q:Can I pick up goods at your factory?
A:Yes, we will quote EXW price for you. When goods are ready, you can arrange picking up.

Q:What's your lead time?
A:It depends on trailer/trailer parts type, and the quantity.

Q:How many units for 1 Container?
A:After confirming specifications, the accurate units will be provided.



Shandong Xiangcai International Trade Co., Ltd. - Your Trusted Partner for Quality Used Trucks.Established in 2020, has rapidly become a leading exporter of a wide range of used trucks, proudly serving regions across the globe. Our extensive inventory includes Flatbed Trailers, Lowbed Trailers, Fuel Trailers, Fence Trailers, Skeleton Trailers, Dump Trucks, Tractor Trucks, and Fuel Tank Trucks, all meticulously selected to meet the diverse needs of our international clientele.
Located in the vibrant city of Qingdao, we leverage our strategic position to offer unparalleled logistics solutions, ensuring that every vehicle reaches its destination in optimal condition and on time. Despite being a relatively young company, we have built a reputation for excellence through our unwavering commitment to quality, reliability, and customer satisfaction. Our team is dedicated to providing personalized services, from initial consultation to after-sales support, making us a preferred choice for businesses seeking reliable and cost-effective transportation solutions.
