4 Colors Automatic Flexo Graphic Label Printer UV Dryer Stack Structure for Printed Labels
- Category: >>>
- Supplier: Hangzhou Prime Intelligent Technology Co. Ltd.Hangzhou Ltd.
Share on (1601356395003):
Product Overview
Description
4 Colors Automatic Flexo Graphic Label Printer UV Dryer Stack Structure for Printed Labels
Product Overview
Application:
The machine can finish material-feeding,printing, varnish, drying, laminating, rewinding and die-cutting in one process is an ideal machine for printing note and top-grade adhesive label.
Features:
1. The flexo printing machine adopts the anilox rollers to spread ink.
2. Unwinding and rewinding of the flexo printing machine is controlled by magnetism power brake, clutch.
3. Printing unit of the flexo printing machine adopt 360º to regulate for registration.
4. Each printing unit of the flexo printing machine has one IR drier.
5. The rubber roller of the flexo printing machine can break away automatically while parking, and running at a low speed, in order to avoid water being dried.
6. The main motor of the flexo printing machine is adopted the import stepless regulation of frequency conversion.
7. Unwinding, printing, varnishing, IR drying, laminating and rewinding of the flexo printing machine can be finished in one process, this kind of printing machine is best for each printing companies to print on adhesive-paper labels and other commercial label.
Product Specifications
Model | PM-FPST320-1200 |
Printing Speed | 60m/min |
Printing Color | 1-10 Colors |
Max Web Width | 320-1200mm |
Max Printing Width | 320-1200mm |
Max Unwinding Diameter | 600mm |
Max Rewinding Diameter | 600mm |
Printing girth | 180.975-444.5mm |
Precision of Overprint | ±0.10mm |
Dimensions | 3730x1150x3000mm |
Machine Weight | 3500kg |
Total Power | 10.5kw |
Machine Details
Standard Configurations
Unwinding
Max. Unwinding Dia 600mm
Rewinding
Auto Web Guide
IR Dryer
Printing Unit
Control Panel
Optional Configurations
LED UV Dryer
UV Dryer
Die Cutting Unit
Slitting Unit
Corona Treater
Laminating
Independent Unwinding Track
Max. Unwinding Dia 1000mm
Cold stamping
Turn bar
Electric Crane
Samples
Our Factory
FAQ
1. Q: How does your factory do regarding quality control?
A: Quality is priority. We always regard great importance to quality controlling from the very small thing (even a small screw we will choose the best quality) from the beginning.
2. Q: What is your after-sales service?
A: Our after-sales service is first class. We have a powerful team to help you solve problems. The Warranty is one year and if the machine is damaged by natural not by human, we can send the new parts to you for free.
3. Q: What is the terms of payment you accept?
A: 30% T/T in advance, 70% T/T balance before delivery. We also accept L/C and Western Union.
A: Quality is priority. We always regard great importance to quality controlling from the very small thing (even a small screw we will choose the best quality) from the beginning.
2. Q: What is your after-sales service?
A: Our after-sales service is first class. We have a powerful team to help you solve problems. The Warranty is one year and if the machine is damaged by natural not by human, we can send the new parts to you for free.
3. Q: What is the terms of payment you accept?
A: 30% T/T in advance, 70% T/T balance before delivery. We also accept L/C and Western Union.
