Portable Waste Lube Oil Purification Plant Lubricant Oil Online Filtering Plant Purifier Filter Machine Processing Systems
- Category: >>>
- Supplier: Chongqing Acore Filtration Co. Ltd.Chongqing Ltd.
Share on (1601359034896):
Product Overview
Description
Product Overview
Vacuum Lube Oil Purifier
Application
The main function of lubricating oil filtration machine is to purify the contaminated lubricating oil, motor oil, gear oil,
hydraulic oil, compressor oil, turbine oil and restore its original performance, it’s a professional oil filtration machine. In the purification processing the filter residue accumulation, resistance increased, flow rate slow, should stop work to cleaning residue.
When lubricating oil filtration machine removes impurity, pay special attention to filter on the stainless steel wire mesh deformation or damage, otherwise, when installed filters again, the purity of the filtered medium can’t meet the design requirements, compressor, pump, instruments and other equipment will be destroyed, once found that stainless steel wire mesh deformation or damage should be replaced immediately. The filter element of lubricating oil filtration machine is composed of special materials, is easily damaged parts, need special protection; When fine filter work after a period of time, the filter to block a load of a certain amount of impurities, the pressure will increase, flow rate will decline, need to remove the impurities in the filter system in time, at the same time to clean the filter element.
Features:
1.High-performance water, gas, and particulate removal
2.Minimizing fluid oxidation, maintaining lubricity properties and reducing aeration and acid build-up.
3. Low watt density oil heaters and digital temperature controller
4. High-quality filter elements with high dirt holding capacity, and filter elements can be cleaned or replaced.
5. Low maintenance requirements, minimal installation requirements and automatic operation
The main function of lubricating oil filtration machine is to purify the contaminated lubricating oil, motor oil, gear oil,
hydraulic oil, compressor oil, turbine oil and restore its original performance, it’s a professional oil filtration machine. In the purification processing the filter residue accumulation, resistance increased, flow rate slow, should stop work to cleaning residue.
When lubricating oil filtration machine removes impurity, pay special attention to filter on the stainless steel wire mesh deformation or damage, otherwise, when installed filters again, the purity of the filtered medium can’t meet the design requirements, compressor, pump, instruments and other equipment will be destroyed, once found that stainless steel wire mesh deformation or damage should be replaced immediately. The filter element of lubricating oil filtration machine is composed of special materials, is easily damaged parts, need special protection; When fine filter work after a period of time, the filter to block a load of a certain amount of impurities, the pressure will increase, flow rate will decline, need to remove the impurities in the filter system in time, at the same time to clean the filter element.
Features:
1.High-performance water, gas, and particulate removal
2.Minimizing fluid oxidation, maintaining lubricity properties and reducing aeration and acid build-up.
3. Low watt density oil heaters and digital temperature controller
4. High-quality filter elements with high dirt holding capacity, and filter elements can be cleaned or replaced.
5. Low maintenance requirements, minimal installation requirements and automatic operation
PRODUCT SPECIFICATIONS
Model | VLF10 | VLF20 | VLF30 | VLF50 | VLF100 | VLF150 | VLF200 | VLF300 | |||||||
Capacity(L/h) | 600 | 1200 | 1500 | 3000 | 6000 | 9000 | 12000 | 18000 | |||||||
Vacuum level | -0.08～-0.095 Mpa | ||||||||||||||
Working pressure | ≤ 0.4 Mpa | ||||||||||||||
Temperature range | 20-80℃ | ||||||||||||||
Demulsifying value | ≤8 min(GB/F7035) | ||||||||||||||
Water content | ≤ 3ppm | ||||||||||||||
Gas content | ≤1% | ||||||||||||||
Filtering rate | 1 micron | ||||||||||||||
Power supply | 208V/220V/380V/400V/415V/440V/460V/480V/575V(±10%), 50/60Hz, 3Phase | ||||||||||||||
Cleanness | NAS 6 grade | ||||||||||||||
Working noise | 65 dB | ||||||||||||||
Heating power (kw) | 15 | 24 | 24 | 30 | 60 | 120 | 180 | 240 | |||||||
Total power (kw) | 17 | 27 | 27 | 33 | 65 | 125 | 188 | 250 | |||||||
Inlet/outlet(mm) | 25 | 25 | 32 | 32 | 44 | 50 | 55 | 65 | |||||||
Weight (kg) | 350 | 400 | 400 | 450 | 600 | 900 | 1200 | 1600 | |||||||
Dimension (L*W*H) | 1100 | 1150 | 1200 | 1300 | 1500 | 1600 | 1700 | 1900 | |||||||
800 | 800 | 850 | 950 | 1000 | 1150 | 1250 | 1300 | ||||||||
1200 | 1250 | 1300 | 1350 | 1500 | 1600 | 1800 | 1900 | ||||||||
Details Images
