Sanyo UF463443GUM 800mAh 3.7V Rechargeable Aluminum Case Lithium Ion Battery Prismatic Battery

Product Overview

Description

The Sanyo UF463443GUM is an 800mAh, 3.7V rechargeable lithium-ion battery with an aluminum case. It features a prismatic shape, which makes it suitable for a variety of applications where a compact and high-energy-density power solution is required. This battery is known for its long cycle life, high energy density, and lack of memory effect, making it a reliable choice for portable electronic devices such as walkie-talkies, cameras, and camcorders. When charging and storing this battery, please ensure to use proper methods and equipment to maintain its performance and safety.



The SANYO UF463443ZU 3.7v 800mAh LiPo (Lithium Polymer) Li-ion (Lithium Ion) battery is a specific type of rechargeable battery that combines the advantages of both lithium-ion and lithium-polymer technologies. Below is a detailed description of this battery:

Basic Specifications

• Model: UF463443ZU


• Battery Type: Li-ion (Lithium Ion) / LiPo (Lithium Polymer)


• Rated Voltage: 3.7V


• Rated Capacity: 800mAh (with some sources indicating a nominal capacity of 820mAh minimum and 850mAh typical)


• Dimensions: The battery has a prismatic shape with specific dimensions. However, the exact dimensions may vary slightly depending on the manufacturing batch and supplier. Typically, the thickness (without the tube) is around 4.55mm, the width (without the tube) is around 33.85mm, and the height (without the tube) is around 42.6mm. The approximate weight is 16.0g.

Characteristics

• High Energy Density: As a lithium-polymer battery, it offers a high energy density, allowing it to store a significant amount of energy in a compact and lightweight package.


• Long Cycle Life: Lithium-ion and lithium-polymer batteries are known for their long cycle life, meaning they can be charged and discharged multiple times without significant degradation in performance.


• Safe and Reliable: SANYO batteries are designed with safety features to prevent overcharging, over-discharging, and short-circuiting, ensuring reliable operation and user safety.

Applications

• Portable Devices: Due to its compact size and high energy density, the UF463443ZU battery is ideal for use in portable electronic devices such as smartphones, tablets, cameras, and other handheld gadgets.


• Wearable Technology: With its lightweight and thin design, this battery can also be used in wearable devices like smartwatches and fitness trackers.


• Industrial and Medical Equipment: Its reliable performance and long cycle life make it suitable for use in industrial and medical equipment that requires a dependable power source.

Precautions for Use and Storage

• Charging: Use only compatible chargers designed for lithium-polymer batteries to avoid damage to the battery or the device it powers.


• Discharging: Avoid complete discharge to preserve battery life.


• Storage: Store the battery in a cool, dry place away from direct sunlight and sources of heat. Avoid storing it for extended periods at full charge to prevent degradation.


• Handling: Handle the battery with care to avoid physical damage, which could compromise its performance and safety.

Supplier Information

SANYO, as a reputable manufacturer of electronic components, including batteries, offers a range of lithium-ion and lithium-polymer batteries tailored for different applications. The UF463443ZU battery is likely to be available through authorized distributors and retailers specialized in electronic components and batteries.

In summary, the SANYO UF463443ZU 3.7v 800mAh LiPo Li-ion battery is a compact, high-energy-density battery suitable for a wide range of portable and wearable electronic devices. Its long cycle life and safety features make it a reliable choice for various applications. When using or storing this battery, it is important to follow the manufacturer's recommendations to ensure optimal performance and safety.
