Oven refractory Ceramic Fiber Blanket heat insulating 1260 Degree Thermal Insulation Ceramic fiber wool mat blankets aluminum
- Category: >>>
- Supplier: Hebei United Energy Tech Co. Ltd.Hebei Ltd.
Share on (1601360260591):
Product Overview
Description
PRODUCT INFORMATION
United Insulation Ceramic Fiber Blanket is made of high quality ceramic fiber spun bulk by using double inside needling methods which improve the tensile strength and the flatness of the cermic fiber blanket.
UET ceramic fiber blanket contains no organic binders which guarantee the stability and constructability of the ceramic fiber blanket at both high temperature and low temperature.
It is widely used for pipe and equipments of pyroelectricity, petroleum-chemical, boats, building, machines, boilers, etc. with the performance of fire prevention, heat insulation, sound absorption, and other so many technical features.
Technical Data of Ceramic Fiber Blanket
| 1050 Common | 1260 STD | 1260HP | 1400 | 1450HZ | ||
| Operation Temp(℃) | 950℃(1742℉) | 1050℃(1922℉) | 1100℃(2012℉) | 1200℃(2192℉) | 1350℃(2462℉) | |
| Density(kg/m3) | 64-160 | |||||
| Permanent Change on Heating(%) | 950℃*24h ≤-3 | 1050℃*24h ≤-3 | 1100℃*24h ≤-3 | 1200℃*24h ≤-3 | 1350℃*24h ≤-3 | |
| Coefficient of Heat Conductivity | 0.15(600℃) 0.22(800℃) | 0.12(600℃) 0.20(800℃) | 0.12(600℃) 0.20(800℃) | 0.12(600℃) 0.20(800℃) | 0.12(800℃) 0.20(1000℃) | |
| Tensile Strength(Thickness 25mm)
| ≥0.04 | ≥0.05 | ≥0.05 | ≥0.04 | ≥0.06 | |
| Chemical content | Al2O3(%) | 44 | 45-46 | 47-49 | 52-55 | 39-40 |
| Al2O3+SiO2(%) | ≥96 | ≥98 | ≥99 | ≥99 | - | |
| ZrO2(%) | - | - | - | - | 15-17 | |
| Al2O3+SiO2+ZrO2(%) | - | - | - | - | ≥99 | |
| Fe2O3(%) | ≤1.0 | ≤0.8 | ≤0.2 | ≤0.2 | ≤≤0.2 | |
| Na2O+K2O(%) | ≤0.4 | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.2 | |
| CaO+MgO(%) | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.2 | ≤0 | |
SPECIFICATIONS
| Product name | 1260 ceramic fiber blanket | |
| Classification temperature | 1260℃(2300℉) | |
| Density | 64kg/m3, 96kg/m3, 128kg/m3 | |
| Size | 15000*610/1220*10mm 14400/14640*610/1220*12.5mm 7200/7320*610/1220*20mm 7200/7320*610/1220*25mm 5000*610/1220*30mm 4500*610/1220*25mm 3600/3660*610/1220*50mm accept customized |
PACKAGING
• Plastic coated woven bag
• Inner plastic bag, outside carton box
• Inner plastic bag, outside carton box, then pallets
• Inner plastic bag, outside carton box
• Inner plastic bag, outside carton box, then pallets
STORAGE AND TRANSPORT
Store insulation indoors. Store product under cover and in dry conditions.
QUALITY MANAGEMENT AND SPECIFICATION COMPLIANCE
ISO 9001: 2008, ISO 14001:2004
GB/T 17430, GB50264, ASTM C411, ASTM C447-03, ASTM C423, GB50264
GB/T 17430, GB50264, ASTM C411, ASTM C447-03, ASTM C423, GB50264
FIRE PERFORMANCE
Classified as Euroclass A1 to STN EN 13501-1: 2007 and FM Certificate
FEATURES AND BENEFITS
• Natural inorganic material
• Class A fire resistance
• Great moisture resistance
• Excellent mod resistance, good chemical stability
• Aging resistance, and corrosion resistance
• Class A fire resistance
• Great moisture resistance
• Excellent mod resistance, good chemical stability
• Aging resistance, and corrosion resistance
| Keep Cool | Keep Warm | Fire Proof | Moisture Proof | Noise Control | Sustainbility | Save Cost | Health Safe |
APPLICATIONS
Flat Steel Deck Roof and Flat Concrete Deck Roof System
NOTICE
Safety first. Follow good safety/industrial hygiene practices during insulation. Wear appropriate personal protective equipment. Read SDS and literature before specification and insulation.
STANDARD & CERTIFICATE APPROVED PRODUCT
 |  |  |  |
UNITED PEOPLE SERVE THE WORLD
