MIG/MMA/Lift TIG 4 in 1 Synergic Control IGBT Inverter Large LED Display HONE MIG Welder 5kg MIG/MAG welding machine
- Category: >>>
- Supplier: Shanghai Hone Mechanical And Electrical Technology Co. Ltd.Shanghai Ltd.
Share on (1601360702526):
Product Overview
Description
Brand Name | HONE |
Model | MIG160 |
Product Number | N055S22 |
Rated Input Power Source (V/HZ) | 1PH ~ AC220V ±15% 50/60Hz |
Rated Input Current (A) | 26.0A(MIG) / 31.0A(MMA) / 19.0A(Lift-TIG) |
Rated Input Power Capacity (KVA) | 5.6KVA(MIG) / 6.8KVA(MMA) / 4.2KVA(Lift-TIG) |
No-Load Voltage (V) | 65V |
Welding Current Range (A) | 20 - 160A(MIG/MMA) / 10 - 160A(Lift TIG) |
Welding Voltage Range (V) | 15 - 22.0V(MIG) / 20.8 - 26.4V(MMA) / 10.4 - 16.4V(Lift TIG) |
Duty Cycle (%) | 40%(MIG) / 35%(MMA) / 45%(Lift-Tig) |
Feature | MIG: Burn back, Inching. MMA: Hot-Start, Arc-Force, Anti-Stick, |
Wire Diameter (mm) | Solid wire & Flux-cored wire Φ 0.6/0.8/0.9/1.0mm |
Wire Spool Capacity (kg) | 5kg (Φ200mm) / 1kg (Φ100mm) |
Wire-Feeding Speed (m/min) | 1.5 - 18 m/min |
Usable Electrode (mm) | Φ 1.6 - 4.0mm |
Electrode Type | E6013, E7018, E6010 etc. |
Workpiece Thickness (mm) | Carbon steel, 0.8 - 9.0 |
Efficiency (%) η | ≥85% |
Power Factor (Cos ¢) | 0.73 |
Protection Class | IP21S |
Insulation Class | H |
Electrical Protection Class | Class I |
Dimension (mm) | 435L 190W 290H (mm) |
Weight (kg) | 7.6kg |
Warranty | 2 Year |
Condition | New |
Place of Origin | Shanghai, China |
Machining, Construction Site, Machinery Repair Shops, Home Use, Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Retail, Shelf Make and Repair, House Construction and Repair, Printing Shops, Construction works , Energy & Mining, Advertising Company | |
Key Selling Points | LED light, High quality performance, deep bath, |
Material / Metal Processed | Capable of welding all kinds of ferrous metals such as medium carbon steel, mild steel, fence, automotive exhaust pipe, stainless steel and cast iron. |
Wire Melting Type | Short-circuit transition |
Mig Solid Wire Diameter (mm) | Φ 0.6/0.8/0.9/1.0mm |
Features
➤MCU digital control technology, super portable and energy saving.
➤Digital interface and Synergic welding makes operation easier for users.
➤Inverter IGBT Single-ended technique makes the welder more strong, with compact size but much high duty cycle.
➤Variable amperage control with ditial meter, for a simultaneous welding current and voltage display.
➤Waveform control, for added stability of the arc, even at low current.
➤Excellent arc characteristics without spatter and deep bath, good shaping.
➤Equipped with temperature, voltage and current sensors for high protection.
➤Suitable for a variety of acidic and alkaline electrode welding.
➤Used in the welding mild steel, carbon steel, low alloy steel.
➤MCU digital control technology, super portable and energy saving.
➤Digital interface and Synergic welding makes operation easier for users.
➤Inverter IGBT Single-ended technique makes the welder more strong, with compact size but much high duty cycle.
➤Variable amperage control with ditial meter, for a simultaneous welding current and voltage display.
➤Waveform control, for added stability of the arc, even at low current.
➤Excellent arc characteristics without spatter and deep bath, good shaping.
➤Equipped with temperature, voltage and current sensors for high protection.
➤Suitable for a variety of acidic and alkaline electrode welding.
➤Used in the welding mild steel, carbon steel, low alloy steel.
Q1. Can you design and make the new products based on customer's requirements?
A:
Sure, based on our strong R&D capabilities, we can customize products according to customer requirements.
Q2. How can we guarantee quality?
A:
Before mass production, we will conduct pre-production samples; before shipment, we will conduct final inspection.
Q3.Why should you buy from us not from other suppliers?
A:
1. 22 years of Professional Welding Equipment production, sales experience.
2. First-Class Technology, Focus on User Experience.
3. Provide customized services to more than 80 customers around the world.
4. High quality and professional after-sales service.
A:
Sure, based on our strong R&D capabilities, we can customize products according to customer requirements.
Q2. How can we guarantee quality?
A:
Before mass production, we will conduct pre-production samples; before shipment, we will conduct final inspection.
Q3.Why should you buy from us not from other suppliers?
A:
1. 22 years of Professional Welding Equipment production, sales experience.
2. First-Class Technology, Focus on User Experience.
3. Provide customized services to more than 80 customers around the world.
4. High quality and professional after-sales service.
