Easun Power Lithium Battery Lifepo4 48v 51.2v 100Ah 200Ah 300Ah Wall mounted BMS Parallel Powerwall 5kwh 10kwh 15kwh Gel Battery
- Category: >>>
- Supplier: EASUN POWER TECHNOLOGY CORP LIMITEDEASUN LIMITED
Share on (1601360718544):
Product Overview
Description
Recommend Products
Specification
Model Name | EA-51.2V-100AH | EA-51.2V-200AH | |
Nominal Voltage | 51.2V | 11000VA/11000W | |
Nominal Capacity | 100AH | 200AH | |
Effciency | ≥96% | YES ( By PV or Utility) | |
lnner Resistance | 10mΩ | 7mΩ | |
Cell Type | LiFePO4 | 170-280 VAC (For Computers) 90-280 VAC (For Home Appliances) | |
Charge Voltage | 58.4V | 50 Hz/60 Hz (Auto sensing) | |
Standard Charging Current | 20A | 40A | |
Max.Continuous Charging Current | 100A | 100A | |
Standard Discharge Current | 20A | 40A | |
Continuous Discharge Current | 100A | 200A | |
Peak Discharge Current | 200A(3S) | 200A | |
Discharge Cut-off Voltage | 42V | Pure sine wave | |
Charge Temperature Range | 0~60°C | <70W | |
Discharge Temperature Range | -10°C~65°C | Yes | |
Storage Temperature Range | -5~40°C | 10ms(For personal Computer); 20ms(For Home Appliances) | |
Storaqe Humidity | 65±20％HR | 48 VDC | |
Size(LxWxH) | 600*407*154mm | 839*486*154mm | |
Package Size (L×W×H) | 705*515*375mm | 705*515*375mm | |
Shell Material | SPCC | 3:1 | |
Net Weight | 50kg | 90kg | |
Gross Weight | 62kg | 108kg | |
Package Method | 1pcs per carton | 48VDC | |
Cycle Life | ≥6000 times cycle @ 100% DOD, 80% capacity remain | 54VDC | |
Self Discharge | 2% per month | 63VDC | |
SOC Indication | LED Light& LCD Screen | CC/ CV | |
Communication Protocol | RS232/RS485/CAN | ||
Products Description
FAQ
1. Who are we?
We are Easun Power factory is a leading high-tech enterprise which established in 2012. It is located in Shenzhen China, sell to
North America(25.00%),Mid East(15.00%),Southern Europe(15.00%),Western Europe(10.00%),South America(5.00%),Eastern
Europe(5.00%),Southeast Asia(5.00%),Africa(5.00%),Oceania(5.00%),Eastern Asia(5.00%),Northern Europe(5.00%). There are total about
50-100 people in our office.
2. Why choose us ?
With strong R&D, manufacture and quality control of inverter products;
We have built a comprehensive sales & marketing network and experienced after-service center;
3. What can you buy from us?
Solar Inverter, Car Power Inverter , Solar Charger Controller,Battery
4. How to order ?
Step 1, please tell us model name or link and quantity you need;
Step 2, then we will make a PI for you to confirm the order details;
Step 3, when we confirmed everything, can arrange the payment;
Step 4, finally we deliver the goods within the scheduled time.
5. When will make delivery ?
Delivery time
-Sample order: 1-3 days after receipt of the full payment.
-Stock order: 3-7 days after receipt of the full payment.
-OEM order: 12-20 days after receipt of the deposit.
6. After-sales Service
1 year warranty for all kinds of Inverter;
If you find any defective accessories after receiving the goods, please contact us at once. we will give you the new parts for
free to replace in the next order after confirmation, as an experienced manufacturer, you can rest assured of the quality and
after-sales service. ( Please refuse to sign if the goods package in broken situation )
7. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,Express Delivery；
Accepted Payment Currency:USD,EUR,CAD,AUD,HKD,GBP,CNY;
Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash,Escrow;
Transportation: DHL, UPS , EMS, FedEx, TNT, Air freight , Sea freight, Train way.
We are Easun Power factory is a leading high-tech enterprise which established in 2012. It is located in Shenzhen China, sell to
North America(25.00%),Mid East(15.00%),Southern Europe(15.00%),Western Europe(10.00%),South America(5.00%),Eastern
Europe(5.00%),Southeast Asia(5.00%),Africa(5.00%),Oceania(5.00%),Eastern Asia(5.00%),Northern Europe(5.00%). There are total about
50-100 people in our office.
2. Why choose us ?
With strong R&D, manufacture and quality control of inverter products;
We have built a comprehensive sales & marketing network and experienced after-service center;
3. What can you buy from us?
Solar Inverter, Car Power Inverter , Solar Charger Controller,Battery
4. How to order ?
Step 1, please tell us model name or link and quantity you need;
Step 2, then we will make a PI for you to confirm the order details;
Step 3, when we confirmed everything, can arrange the payment;
Step 4, finally we deliver the goods within the scheduled time.
5. When will make delivery ?
Delivery time
-Sample order: 1-3 days after receipt of the full payment.
-Stock order: 3-7 days after receipt of the full payment.
-OEM order: 12-20 days after receipt of the deposit.
6. After-sales Service
1 year warranty for all kinds of Inverter;
If you find any defective accessories after receiving the goods, please contact us at once. we will give you the new parts for
free to replace in the next order after confirmation, as an experienced manufacturer, you can rest assured of the quality and
after-sales service. ( Please refuse to sign if the goods package in broken situation )
7. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,Express Delivery；
Accepted Payment Currency:USD,EUR,CAD,AUD,HKD,GBP,CNY;
Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash,Escrow;
Transportation: DHL, UPS , EMS, FedEx, TNT, Air freight , Sea freight, Train way.
