Free Shipping Deep cycle solar battery 12v100ah front terminal battery 90ah 105ah 120ah Lead acid battery for backup power

Product Overview

Description



Our advantages

Material

Grade A original lead material, purity 99.995%

Production time

make lead plate ourself , delivery time about one week

Price

We are big factory and prodce lead plate instead of purchasing,  so can control the cost ,quality and production time easily.

Technology

advanced welding machine ,not easy shourt-circuit ,ensure batteries long life.

Quality

 All batteries should tested 3 times before packing to ensure quality OK.

Package

professional workers ; Non fumigation pallets can exported to all countries .



Parameter:

12v 100ah front terminal battery characteristic
Nominal voltage				12V
Nominal capacity(20h rate)				100Ah
Size		Total height		242mm
		length		507mm
		width		110mm
		height		238mm
Weight				29kg
Rated capacity                       25°C(77°F)	10 hour rate(10A)			100Ah
	5 hour rate(15A)			80Ah
	1 hour rate(60A)			60Ah
Internal resistance	in full charge status 25°C(77°F)			3mΩ
Capacity at different temperature(10h)	40°C(104°F)			102%
	25°C(77°F)			100%
	0°C(32°F)			85%
	-15°C(5°F)			65%
Self discharge     25°C(77°F)	capacity after 3 months			91%
	capacity after 6 months			82%
	capacity after 12 months			64%
Mode of charge (constant voltage)       25°C(77°F)	cycle-use		initial charging current less than40A ,                    voltage14.10-14.40V
	float-use		Initial charging current less than 15A voltage13.50-13.80V





 Related model :   color can be customized as customer need

Main application:







Product Certificate:

Package:  each battery in a carton box , 30 cartons in a stardard exporting pallet
