Hot Selling High Quality WA6513 6/8 Tower Cranes 6 Ton 8 Ton Tower Crane For Building Construction
- Category: >>>
- Supplier: Caterbe Construction Equipment (Wuhan) Co. Ltd.Caterbe Ltd.
Share on (1601362255209):
Product Overview
Description
Product Overview
WA6513-6/8 Tower Crane
The WA6513-6/8 tower crane is a self-climbing multi-purpose machine with a horizontal jib, a trolleying mechanism and an upper slewing mechanism. The features of this machine are:
1. The performance parameters and technical indicator of the crane are at a leading level in China and up to the international advanced level. The maximum working radius is 65m and the maximum hoisting height is 190m.
2. Multiple working methods and wide application range. This machine has working methods such as: outrigger stationary,undercarriage stationary, anchored to the building, so that it is applied in different construction projects. The hoisting
height of the outrigger stationary or the undercarriage stationary is 51m. The hoisting height of the crane anchored to the building reaches to 190m based on the outrigger stationary or the undercarriage stationary, added the tower sections and anchored devices.
1. The performance parameters and technical indicator of the crane are at a leading level in China and up to the international advanced level. The maximum working radius is 65m and the maximum hoisting height is 190m.
2. Multiple working methods and wide application range. This machine has working methods such as: outrigger stationary,undercarriage stationary, anchored to the building, so that it is applied in different construction projects. The hoisting
height of the outrigger stationary or the undercarriage stationary is 51m. The hoisting height of the crane anchored to the building reaches to 190m based on the outrigger stationary or the undercarriage stationary, added the tower sections and anchored devices.
PRODUCT SPECIFICATIONS
No | Item | Data |
1 | Model name | WA6513 |
2 | Trolleying mechanism | Speed m/min : 0～100 |
Power kw : 4.0 | ||
3 | Slewing mechanism | Speed m/min : 0 ～0.8 |
Power kw : 5.5×2 | ||
4 | Jacking (Erecting) mechanism | Working pressure MPa : 31.5 |
Speed m/min : 0.58 | ||
Power kw : 7.5 | ||
5 | Total power kw | 40.0+2×5.2 (Excluding erecting mechanism) |
6 | Working temperature ℃ | －20～＋40 |
FEATURES AT A GLANCE
