Portable Small MMA 250A Mig Mma Welder Arc Welding Machine 120A/220V
- Category: >>>
- Supplier: Zhejiang Lingba Welding Equipment Co LtdZhejiang Ltd
Share on (1601363012978):
Product Overview
Description
Description
Mini ARC MMA Welding Machine,110/220V 120A Stick Welder with Synergic Control, Mini Welder with Digital Display
Features
[Easy Operation] - The MINI ARC200 is very easy to use and can be used for practice and small welding operations. Equipped with intelligent digital display, reading welding current. Easy to operate, safe and convenient, especially suitable for beginners.
[Bivolt: 110/220V]small inverter welder automatically matches 110V and 220V. 3.2mm welding rod could be ignited. 10-105A at 110V, 10-120A at 220V.
[Ultra-mini Portable ARC Welder]The welder machiner is compact and light weight.The stick welder has an easy to carry adjustable shoulder strap for easy carrying or use between job sites.ARC200 built in protection equipment internally to prevent over heat, over current to make sure safely operation
Specification
| Model | MMA-200A |
| Type | IGBT 1 PCB |
| Output current range(A) | 120A |
| AC Input Voltage(V) | 110V, 220V, 110V/220V |
| Rated Input Power Capacity(KVA) | 5 |
| Input Frequency(Hz) | 50/60 |
| Non-load Voltage(V) | 60 |
| Rated Duty Cycle(%) | 60 |
| Efficiency(%) | 0.85 |
| Class of Insulation | F |
| Protection class of case | IP21 |
| Electrode diameter(mm) | 1.6-3.2 |
| Connector Size(mm) | 10-25 |
| Input power cable(m) | 1.5 |
| N.w./G.w.(kg) | 2.5/3.5 |
| Machine Size(LxWxH mm) | 260*100*160 |
| Package Size for machine: | 300*160*200 |
| Package Size for 4pcs in 1 large | 670*310*220 |
| Accessories | 1.8m 200A holder |
| 1.2m 200A clamp | |
| Mask, Brush, Belt, Manual | |
| MINI & Portable type | |
| Features | 1year Warranty |
| 1.6~3.2mm welding electrode |
