Good price 25 Ton Mobile Crane STC250 truck crane 25 t crane truck
Good price 25 Ton Mobile Crane STC250 truck crane 25 t crane truck
Good price 25 Ton Mobile Crane STC250 truck crane 25 t crane truck
Good price 25 Ton Mobile Crane STC250 truck crane 25 t crane truck
Good price 25 Ton Mobile Crane STC250 truck crane 25 t crane truck
Good price 25 Ton Mobile Crane STC250 truck crane 25 t crane truck
Good price 25 Ton Mobile Crane STC250 truck crane 25 t crane truck

Good price 25 Ton Mobile Crane STC250 truck crane 25 t crane truck

Share on (1601363015068):


Price:$80,000.00-95,000.00

Quantity:


Product Overview

Description



Product Overview


Contact Way


Durant Zhang
Sales Manager
Whats app/Mobile:+86 18721666299
Email:durant@richmchn.com


Products Description




High-Quality Premium 25-Ton Stc250t Truck Crane Is Available for Sale Now


 * STC250 truck crane boasts excellent traveling performance. the double-axle drive is applied to provide good mobility.
Trafficability and comfortableness under the complex road condition is improved with reliable traveling performance.

Powerful Lifting Capacity
STC250 25 ton crane has four-section boom of high strength steel structure and optimized U-shaped cross section with
max.lifting capacity of 25t, full-extended boom length of 33.5m, max.lifting height including jib of 42m, reduce weight and
improve safety significantly.
Jib mounting angles are 0°, 15°, and 30°, which ensure fast and convenient change-over between different operating conditions
so as to improve working efficiency of the machine.


Product Parameters


Capacity
Max. lifting capacity
25t
Dimensions
Overall length
12750mm
Overall width
2500mm
Overall height
3550mm
Axles
3
Axle distance-1,2
4325mm
Axle distance-2,3
1350mm
Weight
Overall weight
30000kg
Front axle load
6500kg
Rear axle load
23500kg
Engine
Model
Cummins
Rated power
213kW/2100rpm
Rated torque
1050N·m/1200~1400rpm
Emission standard
Euro Ⅲ
Traveling
Max. traveling speed
80 km/h
Min.turning radius
10 m
Min.turning radius of boom head
12 m
Drive train
6×4
Min. ground clearance
220mm
Approach angle
17 °
Departure angle
12 °
Max. gradeability
38%
Fuel consumption per 100km
≤ 37L
Main Performance
Temperature range
– 30 ℃~ + 60 ℃
Min.lifting radius
3m
Tail swing radius of superstructure
3.37m
Boom section
4
Boom shape
U-shaped
Max. lifting moment-Base boom
962kN·m
Max. lifting moment-Full-extend boom
544kN·m
Max. lifting moment-Full-extend boom+jib
341kN·m
Length-Base boom
10.65m
Length-Full-extend boom
33.5m
Length-Full-extend boom+jib
41.5m
Outrigger span(Longitudinal/Transversal)
5.3m × 6.2m
Jib offset
0 ° 15 ° 30 °
Working Speed
Max. single rope lifting speed of main winch(no load)
≥120m/min
Max. single rope lifting speed of auxiliary winch(no load)
≥120m/min
Full extend/retract time of boom
70 / 50s
Full raise/lower time of boom
70 / 55s
Swing speed
0~2 r/min
Aircondition
HVAC in up cab
Cooling and Heating
HVAC in low cab
Cooling and Heating


Details Images




Company Profile




Richmchn Machinery Engineering (Shanghai) Co., Ltd.


Richmchn Machinery Engineering (Shanghai) Co., Ltd. is an engineering & construction machinery provider in Shanghai, especially for construction machinery, heavy industrial equipment and vehicle. We had exported famous international brand around the world. With over 10 years experiences in the field of engineering industry and accompanying to fulfill strictly industrial standard, RICHMCHN had established and have been consistently keeping long term business relationship with many general contractors, civil engineering firms and construction companies throughout the world.

We participated as package equipment provider previously include rural and municipal road projects in Southeast Asia, civil projects in Middle East, airport projects in Africa, dredging projects in South America, building projects in Oceania, and we are still achieving more and more projects at present. We are always committed to offer our customers quality products with reliable performance, competitive price and comprehensive services, to ensure every engineering project to be run smoothly and on schedule.

To provide reliable products with quick delivery time, to make prompt reaction for spare parts and after-sales services, to visit the users field regularly for local training and maintenance, RICHMCHN has been often praised by our customers and has taken great reputation as a trustworthy inproject partner.

RICHMCHN believe in combining our own achievement together with our customer benefits. Open communication, effective planning and elaborative preparation always commit us to execute and deliver our promises for our customers all over the world.
