  • Yaweh diesel offroad 4x4 forklift truck made with closed cabin in china 10T Cross country Forklift
Yaweh diesel offroad 4x4 forklift truck made with closed cabin in china 10T Cross country Forklift
Yaweh diesel offroad 4x4 forklift truck made with closed cabin in china 10T Cross-country Forklift
Yaweh diesel offroad 4x4 forklift truck made with closed cabin in china 10T Cross-country Forklift
Yaweh diesel offroad 4x4 forklift truck made with closed cabin in china 10T Cross-country Forklift
Yaweh diesel offroad 4x4 forklift truck made with closed cabin in china 10T Cross-country Forklift
Yaweh diesel offroad 4x4 forklift truck made with closed cabin in china 10T Cross-country Forklift
Yaweh diesel offroad 4x4 forklift truck made with closed cabin in china 10T Cross-country Forklift

Yaweh diesel offroad 4x4 forklift truck made with closed cabin in china 10T Cross country Forklift

Share on (1601363209835):


Price:$18,000.00-19,800.00

Quantity:


Product Overview

Description







Yaweh Heavy Industries Off-road forklift truck parameters





 Overall dimensions
Engine
1
Dimension（mm)
4700*2100*2970
1
Model
Yudong 4105 supercharged
2
Wheelbase（mm）
2500
2
Form
Turbocharged
3
Wheelbase（mm)
2008
3
Power Rating（KW)
85
4
Minimum Ground Clearance（mm)
370

4
Rated speed（r/min)
2400
Performance Parameters
5
Cylinder bore
105
1
System pressure（Mpa)
16
Drivetrain
2
Weight of the whole machine（kg)
7000
1
Transmission
Powershift
3
Maximum speed（Km/h)
30
2
Number of gears
Front 2 and back 2
4
Maximum climbing capacity（°）
30
3
Torque converter model
280 split high and low speed
5
Minimum turning radius（mm)
5500
Axle
Rough terrain forklift parameters
1
model
Large wheel side bridge
1
Maximum lifting height（mm)
3000-6000
Tires
2
Maximum unloading height（mm)
6800
1
Specification
16/70-24
3
Forward leaning angle（°)
10
2
Braking form
Brake disc brake
4
Fork tooth length(mm)
1520
3
Parking brake
Manual brake
5
Maximum lifting height
11000 mm
Other parameters
6
Maximum lifting weight
3000 kg
1
Drive form
Four-wheel drive
Steering System
2
Variable speed form
Hydraulic variable speed
1
Form
Fully hydraulic steering
3
Operating System
Electromagnetic hydraulic pilot system
2
Steering angle（°）
38







TECHNICAL PARAMETERS
PRODUCT SIZE
Overall dimension(mm)
4550x1610×2570
Min.ground dearance(mm)
120
Wheel track(mm)
1120
PERFORMANCE PARAMETER
System pressure(Mpa)
16
Opera ng weiht(Kg)
2800
Maximum speed(Km/h)
50
Max.climbing capacity(°)
25
Min.tuming radius(mm)
2310
MINING PARAMETER
Bucket capacity(m3)
0.12
Bucket width(mm)
475
Boom length(mm)
1860
Max excavation radius(mm)
3500
Max.digging depth(mm)
2350
Max.excavation height(mm)
3360
Excavation unloading height(mm)
2280
Tuming Angle
180
FORKLIFT PARAMETER
Max lifting height(mm)
3100
Max.unloading height(mm)
2430
Max.deadweight (Kg)
1000
Bucket width(mm)
1590
Bucket capacity(m3)
0.6
OTHER PARAMETERS
Engine type
Yun nei 490
Rated power(KW)
37
Rated speed(r/min)
2400
Number of cylinders-bore diameter
4-90
Steering patterm
Articulated full hydraulic steering
Steering Angle(°)
40
axle
50bell
tyre size
12-16.5
Service brake
Gas cap oil damp disc brake
Parking brake
handbrake
Driving type
Four wheel dr ve
Speed change type
Hydraulic speed change
Excavation unloading heightm(L)
47.5
Hydraulic tank volume(L)
47.5






FQA


Q：Why choose Yaweh?
A：We sell every machine at a fair price.As our production increases,we are getting much support from the
purchase source of raw material.We leave the maximum profit to customer.
1) An experienced loader manufacturer with over 11 years.
2) Customers-focused,you'll get reply within 5 minutes.
3) Premium quality with reasonable price.
4) CE,BV,SGS,ROPS and FOPS,IS9001:2008 verified.
5)The quality control is not an empty word inYAWEH.Our products are tested and granted CE certificate.
Q：What is Yaweh warranty?
A：YAWEH has a professional sales and after-service team.We are trying our best to make a good service for
every customer.
1)Yaweh after-sales: life-long,meantime offer one year warranty.
2) Yaweh proposal: order some wearing parts with
loader for easy maintenance.
Q：What about Yaweh delivery term?
A：Yaweh Transport packaging team helps our customer to transport their machine in safe and secure way without any damage.30-45days after down payment received.
