Stock 12V 24V 48V DC to 110V 120V AC Solar Charger 800w 1200W 2400w 1kva 1.5kva 3kva Pure Sine Wave Power Inverter for home
- Category: >>>
- Supplier: Guangdong Chuangfeng New Energy Technology Co. Ltd.Guangdong Ltd.
Share on (1601367147173):
Product Overview
Description
Product Description
Product Paramenters
Model | HB0512 | HB0812 | HB1012 | HB1512 | HB1524 | ||||
AC Input voltage | 220v/110v | ||||||||
Input voltage range | 220V:145-275VAC+3V 110V:73-137VAC±3V | ||||||||
Input frequency | 50/60Hz±5% | ||||||||
Out put power | 400W | 640W | 800W | 1200W | 1200W | ||||
AC model output Voltage | The same as input voltage | ||||||||
AC model output Frequency | The same as input voltage | ||||||||
Battery model output frequency | 220VAC+10%(110VAC+10%) | ||||||||
Battery model output frequency | 50HZ or 60HZ±1% | ||||||||
Battery model output wave | Pure sine wave | ||||||||
Battery model output voltage | 220VAC±3% | ||||||||
Battery type | Lead acid battery/water battery/lithium battery | ||||||||
Battery voltage | 12V | 24V | |||||||
Battery charging voltage | 13.75VDC | 27VDC | |||||||
Maximum AC Charge Current | 8A | 13A | 18A | 30A | 15A | ||||
Battery charging voltage range | 150-280VAC | ||||||||
Transfer time | ≤10ms | ||||||||
Load peak ratio | (MAX)3:1 | ||||||||
ECO Mode（W） | 6W | 8W | 9W | 11W | 12W | ||||
Protection | Overload /short circyit/Low voltage/Battery reverse connection protection | ||||||||
Status Display | AC voltage/Ac freguency/output frequency/Battery voltage/Load current | ||||||||
Audible alarm | Low battery protection buzzer long beep Low battery buzzer every second Overload buzzer longOverload less than 130%, buzzer every second;overload more than 150%, after 300ms, it will turn off Machine fault buzzer long | ||||||||
Working temperature | 0°C~40°C | ||||||||
Storage temperature | 负15°C~45°C | ||||||||
Relative temperature | 负10°C~90°C No condensation | ||||||||
Noise | <45dB | ||||||||
Dimention ( mm） | 300*144*213 | ||||||||
Net weight(kg) | 6.5 | 6.9 | 7.8 | 8.59 | 9.5 | ||||
Model | HB2024F | HB3024F | HB3048F | HB5048F | HB10048F | ||||
AC Input voltage | 220v/110v | ||||||||
Input voltage range | 220V:154-264VAC+3V(Normal mode) 185-264VAC±3V(UPs mode) 110V:77-132VAC±3V( Normal mode, 92-132VAC±3V( UPs mode) | ||||||||
Input frequency | 50/60Hz±5% | ||||||||
Out put power | 1600W | 2400W | 2400W | 4000W | 8000W | ||||
AC model output Voltage | The same as input voltage | ||||||||
AC model output Frequency | The same as input voltage | ||||||||
Battery model output frequency | 220VAC+10%(110VAC+10%) | ||||||||
Battery model output frequency | 50HZ or 60HZ±1% | ||||||||
Battery model output wave | Pure sine wave | ||||||||
Battery model output voltage | 220VAC±3% | ||||||||
Battery type | Lead acid battery/water battery/lithium battery | ||||||||
Battery voltage | 24V | 48V | |||||||
Battery charging voltage | 27VDC | 54VDC | |||||||
Maximum AC Charge Current | 20A | 30A | 15A | 22A | 56A | ||||
Battery charging voltage range | 150-280VAC | ||||||||
Transfer time | ≤10ms | ||||||||
Load peak ratio | (MAX)3:1 | ||||||||
ECO Mode（W） | 15W | 16W | 16W | 23W | 32W | ||||
Protection | Overload /short circyit/Low voltage/Battery reverse connection protection | ||||||||
Status Display | AC voltage/Ac freguency/output frequency/Battery voltage/Load current | ||||||||
Audible alarm | Low battery protection buzzer long beep Low battery buzzer every second Overload buzzer longOverload less than 130%, buzzer every second;overload more than 150%, after 300ms, it will turn off Machine fault buzzer long | ||||||||
Working temperature | 0°C~40°C | ||||||||
Storage temperature | 负15°C~45°C | ||||||||
Relative temperature | 负10°C~90°C No condensation | ||||||||
Noise | <45dB | ||||||||
Dimention ( mm） | 385*190*382 | 552*190*382 | |||||||
Net weight(kg) | 14.6 | 17.2 | 17.85 | 22 | 36.1 | ||||
Company Profile
FAQ
Q1：May I take some samples to test before placing the order ?
A1：Yes, welcome to take some sample to test!
Q2：How about the delivery time?
A2：7 days for sample; 25 days for bulk order.
Q3：What payment methods do your company support?
A3：T/T, Western Union, Paypal, L/C etc.
Q4：Are you manufacturer or Trader?
A4：We are Focus on Solar Product Manufacturer 20+ years, and we accept OEM / ODM for products.
Q5：What are the price terms can you offer for us?
A5：We can accept EXW, FOB, CIF and so on.
Q6：Do you have any certifications for your products?
A6：We have ISO9001:2000, CE, RoHS, certificates for all of our products.
A1：Yes, welcome to take some sample to test!
Q2：How about the delivery time?
A2：7 days for sample; 25 days for bulk order.
Q3：What payment methods do your company support?
A3：T/T, Western Union, Paypal, L/C etc.
Q4：Are you manufacturer or Trader?
A4：We are Focus on Solar Product Manufacturer 20+ years, and we accept OEM / ODM for products.
Q5：What are the price terms can you offer for us?
A5：We can accept EXW, FOB, CIF and so on.
Q6：Do you have any certifications for your products?
A6：We have ISO9001:2000, CE, RoHS, certificates for all of our products.
