LA16JE—Articulating Boom Lift-Electric
* Safe And Reliability ：Working platform overload protection, 230kg unlimited ;High precision working platform weighing sensor, continuous monitoring of platform load;Imported hydraulic and electraical compenents,work more reliable.* Efficient And Comfortable：Electro-hydraulic proportional control technology, smooth and comfortable work;Combination leveling mechanism, work more stable ;Integrated swivel mechansim, swivel more smoothly;AC walking drive control system, strong power, drive more effificient.
Product Paramenters
Max.Working Height | 17.8 m |
Max.Platform Height | 15.8 m |
Max.Operating Range | 9.78 m |
Overall Length(Stowed) | 7.2 m |
Overall Width(Stowed) | 2.3 m |
Overall Height(Stowed) | 2.35 m |
Overall Length(Transport) | 7.2 m |
Overall Width(Transport) | 2.3 m |
Overall Height(Transport) | 2.35 m |
Turntable Tailswing(Raised) | 0 m |
Platform Size(L×W×H) | 1.83×0.76×1.1 m |
Tyres | 33x12-20(Solid off-road tyre)（Solid off-road tyre） |
Platform Load(Unrestricted/Restricted) | 260 kg |
Gradeability | 45 % |
Max.Working Slope | X-5°/Y-5° |
Turret Rotation | 360°(Discrete) |
Drive Steering Type | 4WD×2WS |
Battery（Lithium） | 51.2V/304Ah |
Charger | 48V/60A |
Hydraulic Oil Tank | 65 L |
Overall Weight | 7300 kg |
