Product Overview

Description











KSD301 Series of thermostat is the use ofthe disctype bimetal sheet beating principle，through the action of the auxiliary mechanism, so that the contact point quickly action, to disconnect or connect the circuit. lt has the characteristics of small size, fixed working temperature, no adjustment, reliable action,economic,strongversatility, and the minimum electromagnetic interference of the wave.


Technical parameter：
Rated voltage：AC250V、AC125AV；
Rated current：10A、16A；
Rated frequency：50/60Hz；
Minimum current：200mA；
Lifespan times：>More than 50000 times；
Operating temperature range：-30℃～350℃；
Action temperature error：±3℃～5℃。
