2.Usage:Solve the problem of dust collection,Especial for the wood dust,littel dust.After drawing into the gas containing impurities,then deliver to the dust collector though nozzles,thereby improve the working enviroment.
3.Feature:Effectively improve the work inviroment.Transmitted medium should be non-hypergolic air and non corrosion air,the temperature of air must below 80 °C.
Voltage,Frequency & Materials could be customized.
Model NO.
(NO.)
Voltage
(V)
Power
(KW)
Air Volume
Air inlet
(mm)
Air Outlet
(mm)
YF-2.2KW
380
2.2
2300
100x3
120
YF-3KW
380
3
2300
100x3
120
YF-4KW
380
4
4600
100x4
150
YF-5.5KW
380
5.5
6500
100x6
180
YF-7.5KW
380
7.5
8000
100x6
180
1.Specialized in industrial ventilation fan manufacturing since 2006
